Juice Bottle Filling Machine Price

FOB Price

US$ 10,000 - 50,000 / Set

1 Set(Min. Order)

Port Shanghai
Payment TermsT/T Money Gram

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Jiangsu, China
Brand Name	Winmark	Model Number	RCGF
Voltage	380V	Power(W)	3.8KW
Weight	4000KG	Dimension(LWH)	295021502400
Processing Types	JUICE	Certification	CE ISO SGS
Warranty	1 Year	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Bottle filling machine price

Products Introduction:
This RCGF W industrial juice machine ash-filling-capping 3-in-1unit:Beverage Machinery is used to produce polyester bottled juice, tea and other non-gas beverage machinery. The RCGF Wash-filling-capping 3-in-1unit:Beverage Machinery can finish all the process such as press bottle, filling and sealing, it can reduce the materials and Outsiders touch time, improve the sanitary conditions, production capacity and economic efficiency.

Characteristics:
1. Using the wind sent access and move wheel in the bottle directly connected technology; canceled screw and conveyor chains, this enable the change the bottle-shaped become easier.
2. Bottles transmission adopt clip bottleneck technology, bottle-shaped transform not need to adjust the equipment level, only change related the curved plate, wheel and nylon parts is enough..
3. The specially designed stainless steel bottle washing machine clip is solid and durable, no touch with the screw location of bottle mouth to avoid secondary pollution.
4. High-speed large gravity flow valve filling valve, filling fast, filling accurate and no liquid lose.
5. Spiraling decline when output bottle, transform bottle shape no need to adjust the height of conveyor chains.
6. Host adopt advanced PLC automatic control technology, the key electrical components from famous company such as Japan's Mitsubishi, France Schneider, OMRON.

Technical parameters:

Model	Washing heads	Filling heads	Capping heads	Capacity (b/h)500ml	Power (KW)	overall dimension(mm)
RCGF16-16-6	16	16	6	3000-4000	2.2	2400X1800X2400
RCGF18-18-6	18	18	6	4000-5000	3.1	2500X1850X2400
RCGF24-24-8	24	24	8	7000-8000	3.8	2900X2150X2400
RCGF32-32-12	32	32	12	10000-11000	5.6	3600X2500X2400
RCGF36-36-12	36	36	12	11000-12000	6.5	3750X2600X2400
RCGF40-40-12	40	40	12	14000-15000	7.2	4000X2800X2400
