Automatic RCGF Series Liquid Filling Machine
Negotiable
/ Set
1 Set(Min. Order)
- Shanghai
- T/T Money Gram
You May Like
Product Details
| Voltage | 380V | Place of Origin | Jiangsu, China | |
| Brand Name | Winmark | Model Number | RCGF | |
| Dimension(L*W*H) | 2950*2150*2400 | Weight | 4000KG | |
| Certification | CE ISO | Condition | New |
Product Description
Specifications
automatic liquid filling machine1.Used for juice or tea
2.Capacity:2000~30000bph
nology from Germany
4.CE,ISO,
automatic liquid filling machine
Products Introduction:
This RCGF Wash-filling-capping 3-in-1unit:Beverage Machinery is used to produce polyester bottled juice, tea and other non-gas beverage machinery. The RCGF Wash-filling-capping 3-in-1unit:Beverage Machinery can finish all the process such as press bottle, filling and sealing, it can reduce the materials and Outsiders touch time, improve the sanitary conditions, production capacity and economic efficiency.
This RCGF Wash-filling-capping 3-in-1unit:Beverage Machinery is used to produce polyester bottled juice, tea and other non-gas beverage machinery. The RCGF Wash-filling-capping 3-in-1unit:Beverage Machinery can finish all the process such as press bottle, filling and sealing, it can reduce the materials and Outsiders touch time, improve the sanitary conditions, production capacity and economic efficiency.
Characteristics:
1. Using the wind sent access and move wheel in the bottle directly connected technology; canceled screw and conveyor chains, this enable the change the bottle-shaped become easier.
2. Bottles transmission adopt clip bottleneck technology, bottle-shaped transform not need to adjust the equipment level, only change related the curved plate, wheel and nylon parts is enough..
3. The specially designed stainless steel bottle washing machine clip is solid and durable, no touch with the screw location of bottle mouth to avoid secondary pollution.
4. High-speed large gravity flow valve filling valve, filling fast, filling accurate and no liquid lose.
5. Spiraling decline when output bottle, transform bottle shape no need to adjust the height of conveyor chains.
6. Host adopt advanced PLC automatic control technology, the key electrical components from famous company such as Japan's Mitsubishi, France Schneider, OMRON.
Technical parameters:
Model | Washing heads | Filling heads | Capping heads | Capacity (b/h)500ml | Power (KW) | overall dimension(mm)
|
RCGF16-16-6 | 16 | 16 | 6 | 3000-4000 | 2.2 | 2400X1800X2400 |
RCGF18-18-6 | 18 | 18 | 6 | 4000-5000 | 3.1 | 2500X1850X2400 |
RCGF24-24-8 | 24 | 24 | 8 | 7000-8000 | 3.8 | 2900X2150X2400 |
RCGF32-32-12 | 32 | 32 | 12 | 10000-11000 | 5.6 | 3600X2500X2400 |
RCGF36-36-12 | 36 | 36 | 12 | 11000-12000 | 6.5 | 3750X2600X2400 |
RCGF40-40-12 | 40 | 40 | 12 | 14000-15000 | 7.2 | 4000X2800X2400 |
