Carbonated Drinks Bottle Filling Line

Name: Carbonated Drinks Bottle Filling Line
Brand: Winmark
SKU: 109367135
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Place of Origin:

Jiangsu, China

Brand Name:

Winmark

Zhangjiagang Winmark Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Jiangsu, China

Brand Name Winmark

Model Number DCGF

Voltage 380V

Power(W) 3.8KW

Weight 4500KG

Dimension(L*W*H) 2950*2150*2400

Processing Types CARBONATED DRINK

Certification CE ISO

Specifications

1. bottle filling line
2. water machine
3. PET bottle
4. full-auto 3 in 1 monoblock

bottle filling line

DCGF series carbonated beverage washing filling sealing machine

It is used for filling carbonated drink in PET bottle or glass bottle. we can supply the whole line.

Characteristics:

1. it can carry out washing filling and capping in one machine.

2. it is very convenient to change diverse sizes of bottles by means of advanced bottle neck clamping & bottle suspending technology.

3. Advanced programmable PLC is equipped to control the main machine. Working speed can be adjusted by frequency conversion device.

4. Main electronic components are all from famous international enterprises, such as OMRON, Mitsubishi

Technical parameters:

Model	DCGF18-18-6	DCGF24-24-8	DCGF32-32-12	DCGF40-40-12
Production Capacity:500ml(B/h)	5000	8000	12000	16000
Suitable Bottle Types(mm):	Round or square square shaped bottle
Polyester Bottle Dimension: (mm)	Bottle diameter:φ50-φ110 Height :150-340mm
Suitable Cap Standard:	Plastic Screw Cap
Filling Precision	≤±5mm
Filling Pressure(Mpa)	0.15-0.35	0.15-0.35	0.15-0.35	0.15-0.35
Rinsing Precision:(Mpa)	0.2-0.25	0.2-0.25	0.2-0.25	0.2-0.25
Installed Capacity:(L)	3.5	4	6	8
Overall Size(mm)(L×W×H)	2450×1800×2350	2780×2200×2350	3600×2650×2350	3800×2950×2400
Total Weight: (kg)	3500	4500	5500	6500
