Product Details
Condition: | New | Type: | Stone Engraving Machine | Use: | Granite |
Production Capacity: | 100% | Place of Origin: | Shandong, China | Brand Name: | Xingchen |
Model Number: | XC-1325 | Voltage: | 380V/50Hz | Power(W): | 5.5KW |
Dimension(L*W*H): | 3200mm*2200mm*1800mm | Weight: | 1500kg | Certification: | CE ISO9001 |
Warranty: | 12 Months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
China Heavy duty structure Stone cnc router granite router engraving cutting machine marble engraving machine
Feature:
1. Whole machine seamless weld steel structure, good rigidity, sturdy and durable, can bear 1MT weight at least. Taiwan HIWIN square guide rails, two linear sliding track; Y axis adopts double drivers, big load, good stability, high precision, long lifetime.
3. Three-axis all have the waterproof and dustproof system, and automatic oil supplier makes the maintenance operation easily.
4. Independent control cabinet, and CNC Router anti-jamming dedicated shielded wire, senior configuration; 3.2kw power water cooling spindle with the imported bearing, large force, high efficiency.
5. Built-in water tank and automatic double direction cutters cooling system protect the tool effectively while processing all kinds of stone.
6. Ncstudio control system that can protect the square guide rails and racks.
7.China made brand stepper motor and driver
Specification:
Model | XC-1325 |
Machine lathe | Whole thicker seamless steel structure |
Work dimensions | 1300*2500*200mm |
Max. feeding height | 300mm or bigger |
Working table | Aluminum T-slot table with stianless steel water tank |
Guide way | Imported HIWIN square orbit from Taiwan |
Driving mode | XY-axis rack pinion, z-axis ball screw |
Mechanical precision | 0.02mm |
Repositioning accuracy | 0.05mm |
Max. Speed | 10m/min |
Working speed | 0-6m/min |
Driving motor | Stepper motor |
Software | Type 3, Art cut, Art cam and Ucancam software |
Voltage | AC 380V 50Hz |
Spindle | 3.2KW water cooling spindle, optional bigger power |
Spindle speed | 0 - 24,000rpm/min |
Control system | Ncstudio control card system, optional DSP control system |
Command | G code, u00, mmg, plt |
Certification | CE |
Marble,granite,standstone,glass,artificialstone,headstone,tablet,such as ceramic engraving and cutting materical.
1. Standard plywood case, its compressive strength and bearing quality is better.
2. the board area is bit, the soil structure is good, it is better in leakproofness and waterproof.
3.when importing, the plywood case is with fumigation-free, the procedure is simple.
1.18 months guarantee of the whole machine,We will provide the consumable parts at an agency price when you need replacement.
2. Our engineer could support you technology to your contry if necessary.
3. Our enginner could service on weekend even on vacation.
4. Our engineer could train you on at our factory for free.
5. Our engineer could service you 24 hours online by skype, yahoo, msn, QQ, or by cellphone.
Contact Us:
Benson Managing Director
Zhangqiu sangyuan Xing Chen Mold Making Co., Ltd
Jinan Yuexing International Trading Co., Ltd.
Add:803 No.2 Building of China Railway 10th Bureau, South Industrial Road,Ji`nan
Tel:531 58875664 Skype:benson.duan QQ:1833617982 Whatsapp:86-15318833253
Web: zqxingchen.en.china.cn jnyuexing.en.china.cn
1. How should i pay for my order ? what is the procession of this purchase ?
we accept TT by bank. you can do 30% prepayment at first, then we will start to make production.
when the machine is ready , we will take pictures to you, and then you can do the ballance.
after we got your payment. i will send the machine to you.
2. How about your service after sales ? can your engineer speak fluent english ?
we offer the service from you got the machine, including how to install the machine,
how to use machine. how to let machine work. and so on. usually we will teach you how to do by email or by skype . our engineer has many years of experience for cnc machine service . he can speak very good english ,
so he can slove the problem in short time.
3.Are you a factory or trading company?
We are the manufacturer . as only the machine made by ourself ,quality can be trusted, and most important thing is we can do better service after sales. we know how to fix the problem in each parts easliy. so welcome to visit to our factory
4. How long is the delivery time?
For standard machines, it would be 7-10 days; For non standard machines and customized machines according to client s specific requirements, it would be 15 to 30 days.
5. How about the documents after shipment?
Aftershipment, we ll send all original documents to you by DHL, including Packing List, Commercial Invoice, B/L, and other certificates as required by client.
