ADC-28400 28.5V DC Aircraft Ground Power Units (GPU) for Sale

Name: ADC-28400 28.5V DC Aircraft Ground Power Units (GPU) for Sale
Brand: ACSOON
SKU: 109354697
Availability: InStock

US$ 999 - 1,999 MOQ: 1 Set

Key Specifications

Place of Origin:

Shaanxi, China

Brand Name:

ACSOON

Model Number:

ADC-28400

Xian Jerrystar Instrument Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any port in China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shaanxi, China

Brand Name ACSOON

Model Number ADC-28400

Output Power Other, >1000KW

Output Type Other, DC

Size Pls consult factory

Weight Pls consult factory

Input Voltage 380v

Output Voltage 28.5v

Type Other, AC/DC

Output Frequency 50HZ

Output Current 400A

Model	ADC-28400
Input
Phase	single phase + PE
Rated Voltage	380V
Range Voltage	323V-437V
Frequency	50hz/60hz
Power Factor(PF)	>0.8
Output
Capacity	400A
Rated Voltage	28.5V
Range Voltage	1V-40V
Voltage Regulation	0.1V
Load regulation	<+-1%FS
ripple content	100mV(rms)
Overload Capacity	125% current 5s
Display
Operating display	rotary switch,push button or LED or LCD touch screen as per your requirement
Voltage Display	1%FS(Full Scale)
Current Display	2%FS(Full Scale)
Protection
Input:Overvoltage,undervoltage	Output:Overvoltage,overcurrent
Overthermal Protection
Reliability
MTRF	1.0*105h
MTTR	0.5h
Effiency	>85%
Noise	Noise
Into the wire way	Back into the line
Cooling method	Fan force cooling
Communication Interface	RS232,RS485
IP Grade	Ip20 or customized
Working Environment
Working temperature	-25°C-50°C(-40°C-60°C)
Humidity	<90%
Altitude	<2000m
Remark:Max. current can reach up 6000A.
