Help CenterA4 Paper PLC High-precision Crosscutting Machine
Related Products
-
A4 Paper Packing MachineUS$ 10,000 - 60,000MOQ: 1 Set -
A4 Paper Machine in FRDNegotiableMOQ: 1 Set
-
3200mm Culture Paper Writing Paper Copying Paper Making EquipmentNegotiableMOQ: 1 Set
-
Qinyang FRD 2400mm Culture Paper MachineNegotiableMOQ: 1 Set
-
1092mm FRD A4 Paper Making MachineNegotiableMOQ: 1 Set
Main Technical Parameters
Model HQJ-1100D HQJ-1400D | ||
Max unwinding diameter | φ1100mm | φ1400mm |
Reference weight of cutting paper | 40~500g | 40~500g |
Max cut width | 1150mm | 1450mm |
Cutting length | 20-1000mm | 20-1000mm |
Cutting speed | 10-150times/min | 10-150times/min |
Cutting precision | ±0.2mm | ±0.2mm |
Voltage: | AC380V/220V x 50HZ | AC380V/220V x 50HZ |
Total power | 10KW | 15KW |
Main function
| 1) can be 1 roll,2roll,4 rolls loading | |
2) With paper stacker | ||
3) With round cutter for slitting | ||
4)With belt transferring | ||
SPARE PARTS LIST
Specification | Num | Rmark |
Spare parts | ||
Round cutter | 5 sets |
|
roud blade | 10 pics |
|
Cross cutter | 2 pic |
|
Mechanical Shaft | 1 |
|
Electrical parts | ||
Swift | 2 unit |
|
Electrograph | 3 unit |
|
minute watch | 1 unit |
|
Switch | 2 unit |
|
Hall switch | 1 unit |
|
Error correction plate | 1 unit |
|
Tension plate | 1 unit |
|
Precison Electrograph | 1 unit |
|
Air parts | ||
Air joint | 1 unit |
|
hand rotate valve | 1 unit |
|
adjust valve | 1 unit |
|
air cylinder | 1 unit |
|
air pressure watch | 2 unit |
|
oir cup | 2 unit |
|
air gun | 2 unit |
|
air neb | 5 unit |
|
Tool box | ||
monkey wrench | 1 unit |
|
hatch wrench | 1 unit |
|
oil gun | 1 unit |
|
Inner hexagonal wrench | 1 unit |
|
double head wrench | 1 unit | 12×14 |
double head wrench | 1 unit | 14×17 |
double head wrench | 1 unit | 22×24 |
cushion of machine | 10 unit |
|
Operation manual | 1 | |
Qinyang City Friends Machinery Equipment Co.,Ltd located in Qinyang City, Henan province, China, is one of leading paper machine manufacture,which specializes in pulp making machine, paper making machine and paper processing machine manufacturing.
Our company has perfect service system. We have engineer team with rich practice experience, who can supply professional service during the whole deal, including technbology consultation, design factory, project evaluation, detailed design of factory, installation and testing the whole production line, training engineers and workers.
