| Model | Flexo Plate | |||
| Thickness(mm) | 3.94mm | 2.84mm | 2.28mm | 1.70mm |
| Rigidity(Shore A) | 38-45 | 38 | 53-56 | 60±2,67±2 |
| Recommend relief depth(mm) | 1.8-2.0 | 1.0-1.2 | 1.0-1.1 | 0.7-0.9 |
| Image reproduction | 5%~95% | 2%~95% | 2%~95% | 2%~98% |
| Maximum line line/inch | 100 | 133 | 133 | 150 |
| Minimum isolated line | 0.3mm | 0.15mm | 0.10mm | 0.10mm |
| Minimum isolated dot | 0.50mm | 0.2mm | 0.15mm | 0.15mm |
| Suitable ink | Suitable for water and alcohol-based ink, incompatible with oil-based ink, hydrocarbon solvent or the ink containing ethyl acetate of more than 25% | |||
| Mainly applicable field | Corrugated board, thick board | Corrugated board, thick board | Label, flexible package, carry bag, folded paper box and beverage package | Film, label, flexible package, carry bag, folded paper box |
| Storage—raw plates | Unexposed plates should be stored in cool areas (4-32°C)away from heat. The plates must be placed flatly, and protected from contacting UV light. It is recommended to unpacked and handled in yellow light. | |||
| Storage—finished Plates | Printing plate should be avoid excessive white light, irradiating from sunlight and exposing in high concentrated ozone environments for a long time either. After being unloaded, the plates should be cleaned thoroughly. | |||
| Guarantee Period |
Under the recommended storage condition, guarantee period of Flexographic Printing Plate is 12 months. | |||
| Packing |
60"*30"(1524mm*762mm), 8 pcs/ctn 40"*30"(1016mm*762mm), 8 pcs/ctn 42"*60"(1067mm*1524mm), 8 pcs/ctn |
80"*50"(2032mm*1270mm), 6 pcs/ctn | 80"*51"(2032mm*1278mm), 10 pcs/ctn | |
Taixing Yalong Printing Equipment Factory,located in Taixing-“Ginkgo Hometown”, is a
professional corporation working on production and sales of positive PS plate, thermal
CTP plate and UV-CTP/CTcP Plate. Quality, price, time is the service tenet of our comp-
-any; Credit, coordination, cooperation is our company’s fundament; Unit, innovation
and objectivity is our company’s enterprise spirit. We will continue to keep a technical
innovation, standardized operation and scienti-fic management. We will use high yield,
superior quality, reasonable prices and perfect service toreturn the elite printing industry.
Fax: 86-523-87428336
MP: 86-18082351999 13852690368
Add: Hongqiao Industrial Park, Taixing, Jiangsu province,China
1. When can I get the price?
We usually quote within 24 hours after we get your inquiry. If you are very urgent, please
call us or tell us in your email so that we will regard your inquiry priority.
2.How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality. We will provide
you sample , as long as you afford the express freight.
3.What about the leading time for mass production?
Honestly, it depends on the order quantity. Normally, 15 days to 20 days after your deposit
if no tooling needed.
