6 Bar Max Pressure Split Pressurized Vacuum Tube Heat Pipe Solar Collector
- Shanghai
- T/T
You May Like
-
Factory Direct Sales All Kinds Of Hot Air Solar Collector
-
Elegant Apperance Balcony Wall-mounted Split Pressure Solar Water Heater
-
Balcony Hanging Solar Water Heater System
-
Up To Date Wall Mounted Heat Pipe Solar Collector
-
58*1800mm Vacuum Tube 24Mm Heat Pipe Solar Collector
-
Newest Design High Quality U Heat Pipe Solar Collector
Product Details
| Type | Evacuated Tube | Pressure | Pressurized | |
| Circulation Type | Indirect / Closed Loop (Active) | Heating System | Thermosyphon (Passive) | |
| Connection Type | Split | Installation | Freestanding | |
| Housing Material | Stainless Steel | Certification | CE, Other, CE, SABS SRCC Solar Kermark | |
| Capacity | 150 | Place of Origin | Zhejiang, China | |
| Brand Name | DIYI | Model Number | DIYI-C01 |
Product Description
| 6 bar Max pressure Split Pressurized Vacuum Tube Heat Pipe Solar Collector |
Solar Water Heater Feature:
1.All the pipeline is made of red copper and conducted by heat transfer medium liquid. With the heat pipe in
the vacuum tube, so no water will flow in the vacuum tube
2.The manifold uses aluminum alloy for exterior, red copper for interior, also with fashion design
3.Withstand high pressure when it is working
4.It can be combined arbitrarily to meet the demand of large water consumption, and also could be combined
with existing pipeline
5.Each tube can work alone, so the solar collector can work even one tube is broken and easy to change if
necessary
Technical Parameters:
Manifold(interior):Red copper
Manifold(exterior):Aluminum alloy
Aluminium fin:1600 mm full length
Heat pipe: Red copper
Heat insulation layer: High density polyurethane foam 50mm/ Eco-friendly rockwool 50mm
Vacuum tube: 58*1800mm 0-50 degree
Hail resistance: 25mm
Max pressure: 6 bar
Heat pipe: Anti-freezing>-35℃
Daily efficiency:= >55%
| Item No. | Solar Vacuum Tube | Absorber Area(m2) | Loading Qty / sets | |||
| qty / pcs | size / mm | 20GP | 40GP | 40HQ | ||
| DIYI-C01-10 | 10 | Φ58X1800 | 1.7X1.12 | 140 | 262 | 323 |
| DIYI-C01-12 | 12 | Φ58X1800 | 1.7X1.16 | 134 | 254 | 313 |
| DIYI-C01-15 | 15 | Φ58X1800 | 1.7X1.26 | 120 | 245 | 291 |
| DIYI-C01-20 | 20 | Φ58X1800 | 1.7X1.64 | 92 | 187 | 222 |
| DIYI-C01-24 | 24 | Φ58X1800 | 1.7X2.10 | 82 | 165 | 195 |
| DIYI-C01-25 | 25 | Φ58X1800 | 1.7X2.12 | 80 | 163 | 193 |
| DIYI-C01-30 | 30 | Φ58X1800 | 1.7X2.38 | 69 | 140 | 166 |
Installation:
1)Experienced Staff
2)Competitive Price
3)Prompt Delivery
4)Small orders acceptable
5)Superior Service
We hope to cooperate with more customers for mutual development and benefits.
