High density polyurethane foam 50mm low pressure solar water heater system price
- 1000 Unit / Units per Month
- Shanghai
- T/T
Product Details
| Type: | Evacuated Tube | Pressure: | Unpressurized | Circulation Type: | Direct / Open Loop (Active) |
| Heating System: | Thermosyphon (Passive) | Connection Type: | Direct-Plug | Installation: | Freestanding |
| Housing Material: | Other, Galvanized Steel | Certification: | CE, Other, CE, ISO9001 | Capacity: | 200 |
| Place of Origin: | Zhejiang, China | Brand Name: | DIYI&OEM | Model Number: | DIYI-NP01 |
Product Description
| High density polyurethane foam 50mm low pressure solar water heater system price |
Solar Water Heater Feature:
| This model solar water heater is one of the most favorite on the international market.It was scientifically and specially designed,is easy to install and operate.The important point is it can feed water automatically and ensure the outlet water as stable temperature,it will always provide you hot water. |
Technical Parameters:
Inner tank: SUS 304-2B/0.41mm
Outer tank: Galvanized steel/0.31mm
Insulation: high density polyurethane foam 50mm
Vacuum tube: 58*1800mm AL-N-AL coating
Bracket:Galvanized steel 1.2m 0-50 degree
Accessories:UV stablilized high temperature silicon
Capacity: 100L 150L 200L 250L 300L
Type | Area(M2) | Vacuum tube | Volume(L) | GrossWeight (KG) | 20GP/40GP/40HQ Loading Qty(sets) | ||
Φ(mm) | Length(mm) | Qty(pcs) | |||||
DIYI-NP01-15 | 1.979 | 58 | 1800 | 15 | 150 | 78 | 53/109/130 |
DIYI-NP01-18 | 2.382 | 58 | 1800 | 18 | 180 | 85 | 48/93/112 |
DIYI-NP01-20 | 2.651 | 58 | 1800 | 20 | 200 | 94 | 40/82/98 |
DIYI-NP01-25 | 3.189 | 58 | 1800 | 25 | 250 | 97 | 30/64/75 |
DIYI-NP01-30 | 3.995 | 58 | 1800 | 30 | 300 | 112 | 25/52/62 |
1)Experienced Staff
2)Competitive Price
3)Prompt Delivery
4)Small orders acceptable
5)Superior Service
We hope to cooperate with more customers for mutual development and benefits.
