New Rotary Encoder Model 1XP8022-10/1024 Original 1XP8022-10

New Rotary Encoder Model 1XP8022-10/1024 Original 1XP8022-10 thumbnail-1
New Rotary Encoder Model 1XP8022-10/1024 Original 1XP8022-10 photo-1
US$ 567.89 - 567.89 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Germany
Model Number:
1XP8022-10/1024
Usage:
Speed Sensor
Contact Supplier Request Quote Chat Now
Beijing Shuntu Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Germany
Model Number 1XP8022-10/1024
Usage Speed Sensor
Theory Optical Sensor
Output Digital Sensor

new rotary encoder model 1XP8022-10/1024 original 1XP8022-10
IXP8022-10/1024 (TTL) made in Germany
Supply : +10 V to +30 V (TTL)
Current input without load: 200mA ;
Maximum load current per output:100mA;
Resolution, Pulses per revolution:1024 P/R ;
Pulse offset between the two outputs:90 ± 20%
Output amplitude: TTL, U High> UB-3.5V, U Low< 3V;
Minimum edge interval: 0.8uS at 160 KHz;
Edge sttepness(without load or cable): t+, t-<200 ns
Maximum frequency : 160 kHz ;
Maximum speed : 9000 /MIN; 9000 rpm
Temperature range -20 C to 100C;
Degree of protection: IP66;
Maximum radial cantilever force: 60N;
Maximum axial force: 40N;
Termination system: 12-PIN ; 12-way plug (socket supplied)
IXP8012-10/1024;
CSA approved encoder; UL certificated rotary encoder;
Weight: 0.5 Kg with package
German encoders in stock:
1XP8012-10/1024
1XP8012-11/2048
1XP8022-10/1024
1XP8022-11/2048
1XP8032-10/1024
