Home > Products > OMRON Sensor > Omron proximity sensor E2EC-C2R5C1 Japanese Omron sensor
Omron proximity sensor E2EC-C2R5C1 Japanese Omron sensor
Negotiable
/ Piece
1 Piece(Min. Order)
- Beijing
You May Like
-
Omron proximity sensor B7AP Power Coupler B7AP-S1 proximity sensor Coupler B7AP-M1
-
Omron Photoelectric sensors E3JM-R4M4T Retro-reflective photoelectric sensor E3JM-R4M4 with MSR function
-
Omron Photoelectric sensor E3JK-5M2 Throughbeam Photoelectric sensor
-
Omron sensor E3JK-DS30M1 Diffuse-Reflective Photoelectric sensors
-
Omron proximity sensor 5mm M5 DC 3-Wire pre-wired proximity sensor model E2E-X1B1 PNP output
-
Omron proximity sensor 5mm M5 DC 3-Wire pre-wired proximity sensor model E2E-X1C1
Product Details
| Place of Origin | Japan | Brand Name | OMRON | |
| Model Number | E2EC-C2R5C1 | Usage | Position Sensor | |
| Theory | Inductance Sensor | Output | Digital Sensor |
Product Description
Specifications
Omron proximity sensor E2EC-C2R5C1 Japanese Omron sensorDC 3-Wire Model , Shielded , 8mm Dia. ,
Sensing Distance 2.5mm
Omron proximity sensor E2EC-C2R5C1 Japanese Omron sensor
DC 3-Wire Model , Shielded , 8mm Dia. ,
Sensing Distance 2.5mm ,
Operation Mode NO
High-sensitivity DC 2-Wire
Sensors and Subminiature
Sensors with Long-distance
Detection
Shielded Sensor Heads from 3-mm to M12 diameters that
can be embedded in metal.
Robotics cables provided as a standard feature
(DC 2-Wire Models).
Indicator provided in Amplifier cable
easy confirmation of operation.
Power supply range of 5 to 24 VDC for DC 3-Wire Models.
DC 2-Wire Models 12 to 24 VDC (10 to 30 VDC), ripple (p-p): 10% max.
3 dia. * E2EC-CR8D1 2M; E2EC-CR8D2 2M
5.4 dia. * E2EC-C1R5D1 2M; E2EC-C1R5D2 2M
8 dia. * E2EC-C3D1 2M; E2EC-C3D2 2M
M12 * E2EC-X4D1 2M; E2EC-X4D2 2M
DC 3-Wire Models; NPN open-collector output
3 dia. *E2EC-CR5C1 2M
8 dia. * E2EC-C2R5C1 2M
Contact Us
- Beijing Shuntu Technology Co., Ltd.
- Contact nameTingting Bao Chat Now
- Phone86-10-68008909
- AddressA1906, No. A4, Chegongzhuang Street
