FASTECH Korea Ezi-Robo Electric Cylinder Actuator MC28VA2G-06OK-P Ezi-SERVO

Name: FASTECH Korea Ezi-Robo Electric Cylinder Actuator MC28VA2G-06OK-P Ezi-SERVO
Brand: fastech
SKU: 109308333

FASTECH Korea Ezi-Robo Electric Cylinder Actuator MC28VA2G-06OK-P Ezi-SERVO thumbnail-1

FASTECH Korea Ezi-Robo Electric Cylinder Actuator MC28VA2G-06OK-P Ezi-SERVO photo-1

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

South Korea

Brand Name:

fastech

Model Number:

MC28VA2G-06OK-P

Contact Supplier Request Quote Chat Now

Beijing Shuntu Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin South Korea

Brand Name fastech

Model Number MC28VA2G-06OK-P

Specifications

FASTECH korea Ezi-Robo Electric Cylinder Actuator MC28VA2G-06OK-P Ezi-SERVO
High performance of Electric Cylinder Actuator;

FASTECH korea Ezi-Robo Electric Cylinder Actuator MC28VA2G-06OK-P Ezi-SERVO

High performance of Electric Cylinder Actuator;

authorized FASTECH distributor China

Korea FASTECH QQ:1904640213

High precision of Mini Cylinder equipped;

High precision lead screw Ezi-SERVO:

high speed, High resolution of closed loop stepping system.

High Rigidity

Cylunder body and cylinder front cover are integrated to maximizes the rigidity and the rigidity and the material body composed of composite materials has been promoting the improvement of the durability. High Accuracy Long life, low noise and durability proven by employing C7 Level lead screw with high precision to ensure smooth high-speed operation. In addition, it enables high-precision position control guarantees +/- 0.01mm repeatability by high resolution position sensors (up to 16000PPR.) mounted on a steppoer motor drive.

High Speed & Fast Response

Electric Culinder equipped with minimal friction of lead screw and Ezi-SERVO, high precision of closed loop stepping control system can greatly reduce positioning time for large inertia of load By holding a constant force and keep pressing Rod onto a Work as same as Air Cylinder and pressing power can be set freely by parameter. In other words, Fastech Electric Mini Cylinder offers powerful and convenient force control without an external sensor. Also the position control to force control switching, power control can be converted to the position control and position control mode for the conversion of the control algorithm to minimize changes to the mechanical part of the mount to minimize the impact Torque origin Function Homing Sensorless parts of the bodies ended after detecting contact with the encoder on the Z-based homing is possible. Therefore, the mechanism of the aging Stopper mounted on the end, regardless of the origin return speed, always reliable, high-speed and high accuracy of the homing sensor is available without. In addition, the origin location and the origin return speed can be adjusted. (Limited to cases where controller embeded drive) Homing with Sensor Freqyently required in the electric cylinder to simplify the operation, homing Limit Sensor Set incorporated. All parts necessary for the origin output equipped in this package so it reduces the effort to install origin sensor in the design manufacture and procurement. High Rigidity LM Guide Application(Limited to Guide Type) In case of a Guide Type, by applying a wider rigidity LM Guide, MC Series maximizes payload mass and the mont and load mechanical parts can be directly installed at Joint's front and upper unit High Performance, Multi-Functional Drive and Controller By adopting high performance of closed loop stepping drive, Ezi-SERVO, it is possible the use pulse input drive and controller embedded drive.

Network Based Uulti-Axis control A maximum of 16 axis can be operated from a PC through RS-485 communications. ALL of the Motion conditions are set through the network and saved in Flash ROM as a parameter. Motion Library(DLL) is provided for programming under Windows 2000/XP.

Position Table Function Position Table can be used for motion control by digital input and output signals of host controller. You can operate the motor directly by sending the position table number. start/stop, origin search and other digital input values from a PLC. The PLC can monitor the in-Position, origin search, moving/stop, servo ready and other digital output signals from a drive. A maximum of 256 positioning points can be set from PLC.

Various Input/Output signals and user-defined functions nput 7 point/Output 1 point signal can be defined according to user's requirements. Therefore, various features can be used without changing of input/output wiring.

Easy-to-yse Teching Pendant Using the teaching pendant only, where the location of a table of data creation and editing of the program, run, jog function, parameter editing and monitoring functions can be performed.

FASTECH korea Ezi-Robo models:

MC28VA2G; MC28VA2S; MC28VA2S-03NK; MC28VA2S-03NK-P; MC28VA2G-06NK; MC28VA2S-06NK; MC28VA2G-06NK-P; MC28VA2S-06NK-P; MC28VA2G-10NK; MC28VA2S-10NK; MC28VA2G-10NK-P; MC28VA2S-10NK-P; MC28VA2S-03NK-M; MC28VA2G-06NK-M; MC28VA2S-06NK-M; MC28VA2G-10NK-M; MC28VA2S-10NK-M; MC28VA2G-060K-P MC28VA2G-1ONK; MC28VA2S-1ONK; MC28VA2G-1ONK-P; MC28VA2S-1ONK-P; MC28VA2G-1ONK-M; MC28VA2S-1ONK-M; MC28VA2S-03OK; MC28VA2S-03OK-P; MC28VA2G-06OK; MC28VA2S-06OK; MC28VA2G-06OK-P; MC28VA2S-06OK-P; MC28VA2G-10OK; MC28VA2S-10OK; MC28VA2G-10OK-P; MC28VA2S-10OK-P; MC28VA2S-03OK-M; MC28VA2G-06OK-M; MC28VA2S-06OK-M; MC28VA2G-10OK-M; MC28VA2S-10OK-M; MC28VA2G-1OOK; MC28VA2S-1OOK; MC28VA2G-1OOK-P; MC28VA2S-1OOK-P; MC28VA2G-1OOK-M; MC28VA2S-1OOK-M; MC28VA2S-030K; MC28VA2S-030K-P; MC28VA2G-060K; MC28VA2S-060K; MC28VA2G-060K-P; MC28VA2S-060K-P; MC28VA2G-100K; MC28VA2S-100K; MC28VA2G-100K-P; MC28VA2S-100K-P; MC28VA2G-060K-M; MC28VA2S-060K-M; MC28VA2G-100K-M; MC28VA2S-100K-M; MC28VA2G-1O0K; MC28VA2S-1O0K; MC28VA2G-1O0K-P; MC28VA2S-1O0K-P; MC28VA2G-1O0K-M; MC28VA2S-1O0K-M;
