4 Digit FX4S Counter/timer FX5S-I 5 Digit Counter Autonics Counter

Specifications

4 digit FX4S counter timer FX5S-I 5 digit counter Autonics counter
authorized Autonics distributor
DIN W48×H48mm, Preset Counter/Timer
48×48mm compact size up/down counter/timer
FX4S provides 1cps/30cps/2kcps/5kcps of counting speed
and supports NPN/PNP input selecting function and decimal point selecting function
(fixed decimal point of display). Also, the series is possible
to set various up/down counting modes so that various user applications can be supported.
*Upgraded counting speed : 1cps/30cps/2kcps/5kcps
*Selectable voltage input(PNP) or No voltage input(NPN)
*Addition of Up/Down input mode
*Avaliable to set a decimal point(Fixed decimal point of display)
*Wide range of input power supply :
 100-240VAC 50/60Hz, 12-24VAC/DC(Option)
*Selectable Counter/Timer by internal DIP switch
*Various time range
*Built-in Microprocessor
FX4, FX4S, FX4-2P,  FX4-I,
FX6,  FX6-2P,  FX6-I,
FX4H,  FX4H-2P,  FX4H-I,
FX4L-2P,  FX4L-I,
FX6L-2P,  FX6L-I,
FX6, FX4H,
