Q235 mild steel U Channel
Material: SS400, ST37-2, A36, S235,JRG1, Q235, Q345 etc.
Standard: GB/JIS/EN/ASTM/DIN and others.
Packing: In Bundle, Fasten by wire rod with tags. Or according to client's requests.
Length: 6meter, 9meter, 12meter
Chinese standard size: 50*37*4.5mm 400*104*14.5mm
Japanese standard size: 50*25*3mm-300*90*13mm
size (mm) |
thickness (mm) |
thickness (mm) |
weight (kg/m) |
50*25 |
3.00~5.00 |
6.00 |
2.37~3.46 |
75*40 |
3.80 |
7.00 |
5.30 |
75*40 |
4.00 |
7.00 |
5.60 |
75*40 |
4.50 |
7.00 |
5.85 |
75*40 |
5.00 |
7.00 |
6.92 |
100*50 |
3.80 |
6.00 |
7.30 |
100*50 |
4.20 |
6.00 |
8.03 |
100*50 |
4.50 |
7.50 |
8.97 |
100*50 |
5.00 |
7.50 |
9.36 |
125*65 |
5.20 |
6.80 |
11.66 |
125*65 |
5.30 |
6.80 |
12.17 |
125*65 |
5.50 |
8.00 |
12.91 |
125*65 |
6.00 |
8.00 |
13.40 |
150*75 |
5.50 |
7.30 |
14.66 |
150*75 |
5.70 |
10.00 |
16.71 |
150*75 |
6.00 |
10.00 |
17.90 |
150*75 |
6.50 |
10.00 |
18.60 |
150*75 |
9.00 |
12.50 |
24.00 |
200*80 |
7.50 |
11.00 |
24.60 |
200*90 |
8.00 |
13.50 |
30.30 |
250*90 |
9.00 |
13.00 |
34.60 |
300*90 |
9.00 |
13.00 |
38.10 |
Are you interested? We can also supply H beam, U channel, Angle bar, and so on.
If anything we can help you, plase contact us. Hope we can have chance to work together.
Waiting for your news.
