Help CenterC065 Digital Automatic Rock Point Load Tester
Related Products
-
C066 Lab Aggregates Accelerated Polishing MachineUS$ 1,600 - 1,700MOQ: 1 Piece -
C067 Civil Laboratory Coarse Aggregate Doria Din Abrasion TesterUS$ 1,200 - 2,000MOQ: 1 Piece
-
Concrete Core Cutting MachineUS$ 800 - 900MOQ: 1 Piece
-
C071 Clearance Rate Method Fine Aggregate Grain Angularity TesterUS$ 120 - 200MOQ: 1 Piece
-
C072 Method of Flow Time Fine Aggregate Roughness TesterUS$ 100 - 150MOQ: 1 Piece
Specifications
Digital automatic rock point load1.Loading method: electric hydraulic pump load
2.Maximum load: 150KN
3.Voltage: 380 v
Suitable for all kinds of rocks, point load strength, can provide the basis for rock grading and calculating the rock compressive strength parameters through the empirical formula.
Technical parameters
1.Voltage: 380 v power: 0.75 kW
2.Loading method: electric hydraulic pump load
3.Maximum load: 150KN
4.Force sensor: 0-200kW±5N (deformation meter: 0-10mm±0.001mm it’s optional), real-time LCD display, can match software connecting the computer with matching software to record the force value, process of the deformation’s original data process, curve graph.
5.The ball end cone roof pressure ball end curvature radius is 5 mm, cone apex angle is 60 ° “place the rock between upper and lower cone platen ball end to test, compression test strength”.
Xi’an Zealchon Electronic Technology Co.,Ltd adhering to the "professional, honest, and providing the best service" business philosophy, with the guidance of professors and researchers from the Well-known institutions in China, developed a series of leading domestic and international standards, Technology class detecting instrument for asphalt and asphalt mixture, Road, bridge deck, geotechnical, structural, etc and OEM designed 12 series more than 100 kinds of laser productswith high power and long service time.
| Packaging Detail: | YS C049 - A Rock triaxial compression tester is packed by standard wooden case |
| Delivery Detail: | 20 days after payment confirmed |
1. Q: Are you a factory or trading Company?
A: We are a factory; we have manufactured many years.
2. Q: Where is your factory located? How can i visit there?
A: Our factroy is located in Xi’an city, Shaanxi Province, China; our clients are warmly
welcome to visit us no matter where are you from.
