Digital Penetrometers for Asphalt Penetration Testing/asphalt needle penetration test
Main features
-The collet nut fixed needle, to ensure that the needle bar and the needle are in the same center line.
-Displacement sensor test, the needle penetration display precision: 0.01 mm
-Equipped with cold light lighting device, had no effect on the asphalt surface temperature
-With a heating device
-The advanced digital temperature sensor enables temperature measurement more accurate.
-Pin and connecting rod are easy disassembly, easy to check the quality
-The printercanoutput directly
-LCDis moreintuitive.
Technical indicators
| Main Technical Indicators | |
| Parameter Names | Details |
| Temperature Range | Test temperature 0 ~ 90 °C± 0.1 °C |
| Needle penetration time | Boot time: 5s, you can set your own |
| Needle penetration range | 0-40mm ± 0.01 mm |
| Time range | 0-60s ±0.1s |
| Total weight of the standard pin and connecting rod | 50g ± 0.05g |
| Weight mass | 50g ± 0.05g |
| Ambient temperature | 5 ~ 40 °C |
| Ambient humidity | less than or equal 85% |
| Power supply voltage | 220V |
| Boundary dimension | 330 × 230 × 520mm |
| Power | 600W |
| Weight | 7.2kg |
| Water bath heating power | 1000W |
| Water bath cooling power | 2 × 150W |
Company Picture
Lab Picture
Certification
Packaging & Shipping
Packaging Details: ASD-box
Shipping Delivery: Sea & Air Transportation
