Features |
Dual inverter control |
|
Frame welded by steel plate | ||
Plasma capstan | ||
Shaft type loading & unloading bobbin | ||
50~100W motor type traversing unit | ||
Timing belts transmission method | ||
Detecting synchronous control spooler to revise system | ||
Weight balance type to detect device | ||
Tension controlled by weight balance | ||
Magnetic brake | ||
Without oil lubrication for bearing | ||
Water immersion lubrication | ||
Technical Data |
Inlet dia.: |
Φ1.2mm~Φ0.6mm |
Outlet dia.: |
Φ0.25mm~Φ0.1mm |
|
Drawing line speed: |
800mpm |
|
Slip ratio of m/c: |
15%+13% |
|
Final slip ratio: |
0~2% |
|
Max. capstan dia.: |
Φ230mm |
|
Fix speed capstan dia.: |
Φ230mm |
|
Spooler bobbin size: |
O.D. Φ300mm |
|
Main motor: |
11kw |
|
Spooler motor: |
3.7kw |
|
Max. loading capacity: |
30kg |
|
Power: |
440V, 50Hz |
|
Lubrication oil capacity: |
40 L/min |
|
Dimension: |
L*W*H (1300*1800*2000)mm |
|
Weight: |
2500kg |
|
Remark |
1. Above technical data can be modified per customer's needs after confirmed with E-Max technical department; |
|
