Non-asbestos Gasket Sheet

Non-asbestos Gasket Sheet thumbnail-1
Non-asbestos Gasket Sheet photo-1
Negotiable MOQ: 2 Tons (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
SANDA
Model Number:
HD2017#
Contact Supplier Request Quote Chat Now
Hebei Hengda Sealing Materials Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
XINGANG TIANJIN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hebei, China
Brand Name SANDA
Model Number HD2017#

non-asbestos gasket

Product Description

non asbestos gasket sheet for oil-resisting  is made from kevlar fiber, NBR, special fiber, filling materials.

Compressed and calendered under high temperature and pressure into a sheet form. Total free of asbestos.

Typical Application

1.Suitable for water, high temperature steam, compressed air, joint part of tubing, valve, heat exchanger.
2.Can be used in oil conditions.
Features:
1.100% not including asbestos
2.Wide range of temperature



Item

Model NO.



HD2016#

HD2017#

HD2018#

HD2019#

Density g/cm3

1.6~1.8

1.6~1.8

1.6~1.8

1.6~1.8

Tensile strength ≥Mpa



7



9

11

11

Compressibility ≥ %

12+/-5

12+/-5

12+/-5

12+/-5

Recovery ≥ %

40

45

45

45

Aging Coefficient

0.9

0.9

0.9

0.9

Stress Relaxation ≤%

45

45

45

45

Steam Sealing

Tmax: 200 ℃
Pmax:2~3Mpa
30min no shock

Tmax: 250 ℃
Pmax: 4~5Mpa
30min no shock

Tmax: 300 ℃
Pmax: 7~8Mpa
30min no shock

Tmax: 300 ℃
Pmax: 8Mpa
30min no shock

Temperature Max.oC

200

250

300

300

Pressure Max. Mpa

1.5

2.0

2.5

3.0

Resistance to media

Water, seawater, steam, fuel, gases, salt solutions

non-asbestos gasket

non-asbestos gasket sheetnon-asbestos gasket sheet
