Ceramic valves
Ceramic Wedge Dregs-Delivering Gate Valve
Features:
1.Surface sealed with structural ceramic to resist abrasion and scouring
2.Bottom and outlet of valve lined with structural ceramic to prevent scouring
3.Dregs-delivering port prevents ash accumulation with tightened closure
4.Inner body coated with anti-corrosive, anti-abrasive finish
Applicable Working Conditions:
Suitable for the severe working conditions of Petroleum Catalytic Cracking Systems or Power Plant Slurry Pipelines containing high-wearing media such as large solid particles.
Technical Specification:
1. Nominal Pressure: Class 150~400
2. Nominal Dimension: 2”~24”
3. Applicable Temp:-40~900℃
4. Connection Type: Flange
5. Driving Mode: Manual/Electric/Hydraulic/Electric-Hydraulic
Metslurry has been specializing in the design and manufacture of unique structural ceramic components and advance ceramic valves since its inception in 1994. Metslurry Advanced Ceramic is at the leading edge of research and development and leads the world in innovative engineered solutions based on advanced ceramics and ceramic to metal assemblies. Our primary objective is to provide “Severe Service Valves for Severe Industries” in a manner that ensures consistent and reliable performance to cater the severe industries.
We take great advantage on manufacture of big size ceramic valves
We lead the way in ceramic material development, valve design, manufacturing and sales. We achieved ISO9001 certification by the DNV in 2000, and certifications from the American Petroleum Institute and CE in 2003. We set the standard for the Ceramic Valve Industry in China.
Advanced ceramic valve manufacturing technology
1.We have received more than 27 patents in ceramic valve technology and apply for new patents
every year.
2.We have been selected to participate in country’s “Torch Plan”.
3.We were awarded the “Innovation fund for small and medium enterprises”.
4.We are the High Tech Enterprise in Shijiazhuang.
We make large size and high pressure ceramic valves
We have 34 series of ceramic valves and over 700 models. We are the ceramic valve
manufacturer with the most complete models. Our largest ceramic valve is 40 inches, our
highest temperature valve is 900 deg C and the highest pressure is 42 Mpa (2500 lbs). We have
developed a number of ceramic materials to address a wide assortment of applications and
conditions.
Our Brand is strong.
From the time we began ceramic valve production our products have been used in the Petroleum,
Chemical, Power, Metallurgy, Military and Aerospace industries and have earned our customers’
praise. Now our products are being used in every province of our country and are being exported
to many countries, including the US, Singapore, Pakistan, Philippines and Syria. We also provide
OEM parts and service to world famous manufacturers.
1.High quality.We can garantee our pump high quality based on the feedback of more than 50 customers as well as our best team and wokers in our factory.
2.Best service:we have our own techanical department providing professional techanical service
3. Full-way Tracing(Client)
4.Fast delievery,we have enough stock to ensure the delievery time.Also if you are in urgent need we could arrange the air transport for you
