OVERVIEW
The MA5616 multi-service access device (hereinafter referred to as the MA5616)
supports the GPON/dual GE upstream transmission and the VDSL2, ADSL2+ and POTS access services.
This document briefly describes the product positioning, characteristics, system architecture, ports, protocols, network applications, device management, and technical specifications of the MA5616.
INTERFACES:
Network interfaces:
1-6 FE ports or 1-6 GE ports
Electrical or optical interfaces
802.3ad port aggregating support
Service interfaces:
64 ports ADSL/ADSL2/ADSL2+ line card
32 ports SHDSL line card
100M/1000M Ethernet access
Hardware ready for FTTP/FTTH EPON
Hardware ready for VDSL2
Hardware ready for WiMAX
• Superior multicast capabilities:
1,000 multicast channels
Powerful IGMP packet processing capability
IGMP pre-join and fast zapping functions
Hierarchical non-block multicast replication
Unique channel preview function
In-service subscriber count
Multicast protocol support: IGMP, IGMP PROXY
Conditional Access based on Port or MAC/IP address
• Refined service awareness and QoS mechanism
Traffic classification based on L1-L7
Rate policing, mirror, redirection, filtering actions, mark 802.1p(3bits) /TOS(3bits) /DSCP(6bits)
according to the classification result
Recognition of subscribers and service types through DHCP Option60/82, PPPoE+, VLAN stacking in
conjunction with upper layer devices
Rate policing, granularity: 64kbps
4/8 priority queues per PORT, scheduling method: PQ/ WRR/ PQ+WRR
• Service wholesale solutions
QinQ support
L2TP support
GRE support
MPLS PE support (in roadmap);
• Layer 2 features
Support Smart-VLAN and Mux-VLAN
4K 802.1Q VLANs and VLAN stacking
16K MAC address table
Port-based MAC address limitation and bindin
802.3ad Port Aggregation
STP/RSTP protocol(802.1D/1W)
• Layer 3 features
Static routing,RIP2,OSPF,BGP-4
DHCP option60/82 and DHCP relay
ARP Proxy
The MA5600 provides various network ports, service ports, and maintenance ports to meet different networking requirements.
Table 1-1 lists the ports provided by the MA5600.
Port Type |
Port Name |
Remarks |
|---|---|---|
Network port |
FE optical and electrical port |
The network port supports the electrical port, single-mode optical port, and multi-mode optical port. They are used to:
|
GE optical and electrical port | ||
Service port |
ADSL2+ port |
It is compatible with ADSL, and its performance is better than ADSL with respect to:
|
SHDSL port |
It supports the symmetrical transmission. The transmission reach ranges from 3 km to 6 km. |
|
VDSL2 port |
It supports:
|
|
Ethernet port |
It provides subtending of the MA5600 shelves. |
|
ATM port |
It supports:
|
|
Maintenance port |
Maintenance serial/network port |
These ports are used for local and remote maintenance. |
Environment monitoring port |
Through the port, various environment parameters collected by the monitoring device are reported to the host. |
Service boards of the MA5600
Board |
Name |
Function |
External Port |
|---|---|---|---|
ADEF |
ADSL2+ over POTS service board |
It supports:
|
64 ADSL2+ ports |
ADBF |
ADSL2+ over ISDN service board |
It supports:
|
64 ADSL2+ ports |
ADEE |
ADSL2+ over POTS service board |
It supports:
|
64 ADSL2+ ports |
SHEB |
SHDSL.bis service board |
It supports SHDSL.bis access. |
32 SHDSL ports |
SHEA |
SHDSL service board |
It supports SHDSL access. |
32 SHDSL ports |
VDEB* |
VDSL2 interface board |
It supports:
|
32 VDSL ports |
VDBD |
VDSL2 interface board |
It supports:
|
32 VDSL ports |
AIUG* |
ATM interface board |
It supports:
|
4 STM-1 ports or 8 IMA E1 ports |
ETHA* |
Ethernet subtending board |
It is used for GE/FE subtending and provides subtending ports. |
8 GE optical/electrical ports or 8 FE optical/electrical ports |
