oil refining machinery
Spec:2~10T/D
Patent No.ZL99252888.7 for oil refining
It can reach Grade2 oil standard,clear oil.
Small oil refining machine
We obtained patent of small scale of high-grade cooking oil machine unit in 2000, the patent No. is
ZL99252888.7.Besides,our researched,developed and produced small scale of high-grade cooking oil machine unit, won gold award on China Exhibition of Patents.
The oil refining machine is for intermittent refining,it has all functions as large and middle scale of refining machine.
Equipment profile:
It has its heat source, electrical control,with features of light weight and electricity saving. Only turning on power and connecting water, prepare little coal or firewood, caustic soda, phosphoric acid,bleaching clay and other materials, the equipment can be operated. Without special workshop and special base, no matter it's outdoor or indoor, it can be operated easily.
Craft flow sheet:
H3PO4 Caustic soda Hot water Bleaching clay
Crude oil ------------- Alkali refining deacidification ------------ Water washing ----------Decolorization
Filtration Vacuum
----------------Deodorization-------------- Finished oil
Introduction of main equipment:
Neutralization pot: For acid refining, alkali refining and water washing.
Decolorization pot: Bleach oil and remove pigment from oil.
Deodorization pot: Remove odor from oil(Made of stainless steel).
Heat conduction oil furnace: Provide heat energy for production,the temperature can reach 280°C.
Vacuum pump: Provide vacuum degree for decolorization and deodorization,up to above 755mgHg.
Air compressor: Dry decolorization bleaching clay.
Filter press: Filter bleaching clay.
Steam generator: Provide steam for deodorization & distillation
Equipment features:
Simple operation, saving investment, suitable for oil whose processing capacity is below 10T/D,such as soybean oil,cottonseed oil, rapeseed oil,sunflower oil and peanut oil, etc.
Specification: 2T/D---10T/D
