Help CenterXK-KT02 Hot Pump Split Air Condition Training Device
Related Products
-
School Training Kits Vocational Training Machine Teaching Demo Device XK-KT01 Air Conditioning Installation Debugging TrainerUS$ 100 - 5,000MOQ: 1 Set -
Central Air Conditioning Training and Testing Equipment / Educational Technology Equipment, Educational Equipment, Training SetsUS$ 100 - 5,000MOQ: 1 Set
-
Air Conditioning Installation Debugging Training DeviceNegotiableMOQ: 1 Set
-
Training Equipment, Common Cycle Refrigeration Didactic EquipmentNegotiableMOQ: 1 Set
-
Teaching Apparatus, Refrigeration System Training EquipmentNegotiableMOQ: 1 Set
System survey:
1 . The refrigerating unit of XK-KT02 Hot Pump Split Air Condition training device is real in order to keep the same pace with the actual teaching .
2 . The whole training device sets refrigeration system , electrical control system and fault simulation system integration . And the system is integrity , and the structure of the system is clear and compacted .
3 . The training apparatus equipped with AC voltage meter , AC current meter , thermometer , pressure gauge , signal lamp and light emitting diode . They can display the real-time work state of the whole air conditioner system clearly .
4 . The equipment has electric control circuit wiring area of the outdoor machine parts . It can complete the judgment of the electrical connection and compressor winding . The device can help students to apply theory to practice and to cultivate their practical ability .
System parameters:
1 . Input power : single phase three wire AC 220V ± 10% 50 Hz .
2 . Installed capacity : < 1 KVA .
3 . Outline size : 1260 mm × 860 mm × 1800 mm .
4 . Refrigerant type : R 22 or fluorine-free refrigerants .
5 . Safety protection : with drain voltage , current leakage protection device .
6 . Device net weight : about 100 kg .
The basic equipment of the device
1 . The training device comprises a training table , outdoor unit , indoor unit , measuring instrument etc. .
2 . Power control unit includes one AC voltage table , one AC current table , a protector and so on .
3 . The pressure detection unit of the cooling system comprises 2 vacuum pressure gauge which can display the pressure both in low voltage side and pressure side when the system work .
4 . The temperature detection unit has 6 thermometers . The thermometers use PT100 sensor , three and a half display . And measure the air inlet and outlet temperature , inlet and outlet temperature of the condenser and the evaporator separately .
5 . A set of special tools .
Training project:
1 . Understanding and operation method of special tool of cooling system .
2 . Refrigeration system pipe welding method .
3 . Understand the refrigeration and heating principle of the air conditioner when it work .
4 . Refrigeration system pressure and leak detection training .
5 . Training of refrigeration system's vacuum pumping and filling refrigerant .
6 . The measurement of air conditioner's electrical components and the system's operation .
7 . Detection and analysis of air conditioner fault .
1) . The troubleshooting process of the machine does not work .
2) . Fault repair process when the air conditioner refrigeration is out of work .
3) . Fault repair process while refrigeration effect of the air conditioner is not good .
4) . Remote failure process troubleshooting .
5) . Troubleshooting process of indoor air guide plate does not work .
6) . Troubleshooting process of indoor unit does not blow .
7) . Repair process of the fault when the buzzer has no sound .
8) . Troubleshooting process of outdoor fan running but the compressor does not work .
9) . Repair process of the fault when air conditioner is not thermal .
10) . Repair process of outdoor fan does not run.
XINGKE Products Specifications
The First-Class Vocational Teaching Equipment Supplier/Manufacturer in People’s Republic of China.
1. Good quality
2. Reasonable design and original layout, be suitable for teaching and training.
2. Reasonable price
3. OEM Service
XINGKE Mainly Products Range:
PRODUCTS SERIES |
Use and Characteristic |
Mechatronics Lab Equipments |
University education college education high school education. educational equipment training device test board apparatus experiment box rig experimental instrument teaching facility Practice set practise model lab sets laboratory bench technical kits vocational education platform didactic assembly rack simulation system testing module estimate modular aid trainer evaluation software science workbench . AC DC servo motor generator electrical electricity safety power electronic electronics analog digital SCM single chip microcontroller microchip PIC AVR 51SCM programmer PLC automation control controller programmable mechanical mechatronics 5 axis freedom robot PID process pneumatic hydraulic sensor measurement panel home appliance intelligent building system auto automotive automobile engine maintence air condition refrigeration refrigerator car truck section vehicle ABS dissection anatomy solar wind energy virtual simulate simulator lathe circuits industrial robot arm metallurgy ironmaking steelmaking steel rolling special engineering machine elevator boiler 3D simulation. |
Electrical Technology Experiment Device | |
Electronic Technology Experiment Device | |
Electrical Automation Teaching Equipment | |
Pneumatic and Hydraulic Technology Lab | |
Wind and Solar Energy & Sensor | |
Intelligent Building Lab | |
Air Conditioning and Refrigeration Training | |
Training Device | |
Industrial Robot Arm Training | |
Sensor and Measurement and Process Control | |
Flexible Production Line Training | |
Product Line Virtual Simulation Training System | |
Special Type of Work Simulation Trainer | |
Automotive Skill Trainer | |
Automotive Engine Trainer | |
Automobile Chassis Series | |
Engine and Transmission Dissection | |
Automotive Electronics | |
Electric Vehicle and Hybrid Power | |
Automotive Detection |
1. The advantage of our Product:
1).We have manufactured for over 10 years.
We are the leading manufacturer of Educational Equipment Industry in China. We have a large group of material suppliers. They are stable and very cooperated due to our big factory strength.
2).The stable output was upon the stable quality. We will schedule the annual orders plan for you upon the stable annual output.
3).Our tech and service team was very powerful and professional.
We always can meet your requirements upon our tech and service. The large group of tech and service team will meet you around 24 hours. And we will develop the new products upon your potential orders.
4).We have our own brand “XINGKE”
5) We supply quality equipment at economical prices.
2. Our Factory:
XINGKE Industry Park located in the Middle Section of IndustryⅡRoad, Zhangqiu, Jinan, Shandong, China. Our factory covered with 1700 square meter.
3. Packaging And Delivery Details:
Packaging Detail: 1. Packaging for training kit: plastic package + carton + plywood pallets
2. Packaging for training equipment: plastic package + plywood pallet
3. As the clients' requirement, print your logo, etc.
Delivery Detail: 20 to 40 days after Received advanced payment (depend on the total amount)
4. After-Service And Training for Foreign User
1. For our exported equipments, the Warranty is one year, within one year, if there is any problem for spare parts(except damage by man-made) We can supply and replacement free of charge. And if exceed one year, we also supply the service, and process to instruct maintain, and instead the parts charge a certain fee.
2. We dispatch our professional and experienced engineer to install equipments and make training for the end users.
5. Reputation:
Our products earn a good reputation among our customers. We welcome customers, business associations and friends from all of the world to contact with us and seek cooperation for mutual benefits.
NOTE: All items are directly from factory, we would allow you a quantity discount, so please contact with me when you plan an order, we will answer back ASAP.
