Specifications
1.ISO 9001 ISO14001, CE2.Precise quality, 100% tested
3.Direct Factory Price based on your quantity
4.After sale service
1, Vocational school exporter 2, Engineer college science kit manufacture 3, Education equipment 4, Technical teaching aid
Power Electronics Lab Equipment, Power Electronic Teaching Device
1. Product structure:
adopt modular desktop structure, hanging box replacement convenient, easy to organize various training project, expand and upgrade are convenient.
2. Main parameters:
Size 1700 mm x 700 mm x 1500 mm;
The power supply: the three-phase five wire ,AC380V, power < 1500 VA.
3. Main components:
the training platform, power board, load board, diode unit, thyristor unit, trigger circuit unit, isolation power supply unit, the signal source unit, sound-light electric circuit unit, temperature control circuit unit, switch power supply unit etc.
4. Main functions:
can finish 9 class thyristor trigger circuit learning and training, 6 class controlled rectifying circuit learning and training, 6 class uncontrolled rectifier circuit learning and training, 5 kind alternating voltage regulation circuit learning and training, 7 class power device characteristics practice, switch power practice, sound and light control circuit training, temperature automatic control training. Have a safety protection function.
5. Annex:
experimental jump line, a multimeter, product manuals.
