Digital Logic Trainer,Educational Science Kit,XK-ELC1005A Digital Logic Experimental Portable Suitcase

Digital Logic Trainer,Educational Science Kit,XK-ELC1005A Digital Logic Experimental Portable Suitcase photo-1
US$ 100 - 300 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
XingKe
Model Number:
XK-ELC1005A
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Shandong, China
Brand Name XingKe
Model Number XK-ELC1005A

Digital Logic Trainer,Educational Science Kit,XK-ELC1005A Digital Logic Experimental Portable Suitcase

1. Product Introduction:

XK-ELC1005A digital logic experimental portable suitcase consists of normal logic gate circuit,RS trigger,here adopts type of principle symbol and jack, it will be convenient for students learning and using the normal logic gate and trigger etc.

2. Training box main parameters:

2.1 Overall Size: 525 (L) x 350 (W) x 130mm (H); Weight: 3.5kg

2.2 The power supply: single-phase power supply, AC 220 V, 50/60 Hz, power≤20VA.

2.3 With grounding protection,over-current protection,power supply indication and main power indication

2.4 Working environment: temperature: -10℃~+40℃

3. Signal Source Technology Parameter:

3.1 DC 12V voltage source, capacity: 0.5A

3.2 DC 5V voltage source, capacity: 1A

4. Accessory for experiment

4.1 K4 Experiment wires: 30 pieces

4.2 Power line: 1pce

4.3 Manual book: 1pce

5. Experiment Project

5.1 Learning structure and working principle of AND gate circuit

5.2 Learning structure and working principle of OR gate circuit

5.3 Learning structure and working principle of NOT gate circuit

5.4 Learning structure and working principle of NAND gate circuit

5.5 Learning structure and working principle of NOR gate circuit

5.6 Learning structure and working principle of the RS flip-flop

5.7 Learning logic algebra

5.8 Study the application of logic gate circuit

5.9 Learning using gate circuit to implement simple logic design

5.10 Learning digital combinational logic circuits

5.11 Study the application of RS trigger

Digital Logic Trainer,Educational Science Kit,XK-ELC1005A Digital Logic Experimental Portable SuitcaseDigital Logic Trainer,Educational Science Kit,XK-ELC1005A Digital Logic Experimental Portable Suitcase

 Digital Logic Trainer,Educational Science Kit,XK-ELC1005A Digital Logic Experimental Portable Suitcase

Digital Logic Trainer,Educational Science Kit,XK-ELC1005A Digital Logic Experimental Portable Suitcase

Digital Logic Trainer,Educational Science Kit,XK-ELC1005A Digital Logic Experimental Portable Suitcase
