Specifications
It is durable for electrical engineering lab training.Suitable for university colledge school teach;
With ISO CE certificated
Vocational Experiment Device Training kits Electrical Technology Trainer
XK-SX5B Electrical Wiring and Assembly Technology Training Device (four-station)
Electrical Engineering Lab Device, CE ISO Certificated Equipment
1. System overview:
XK-SX5B electrical wiring and assembly technology training device(four-station) consists of training table and mesh board. The training platform offers AC power, DC power. The power part has short circuit, over current and leakage protection and so it is safe and reliable.
The training table body is a steel plate structure and sprayed, its table top is a high density plate which is fire prevention, waterproof and wearproof. It suitable for four persons to sit, provides four electrician training mesh boards, four sets of reference power supply and four person can do practice training at the same time. Training platform can be determined by oneself ,can select the corresponding components according to actual training project and so it is easy to expand.
2. Technical specifications:
2.1.Power part:
1.Input voltage:AC380V±10%,50Hz,three-phase four-wire;
2.Three-phase main power switch equipped with leakage protection;
3.Three-phase,single-phase output equipped with automatic air switch, volume 10A;
4.Accident emergency button, power indication, power supply indication;
5.Mains socket...
2.2.signal source:
1.+24V DC voltage source equipped with switch and short-circuit protection
2.24V AC voltage source equipped with switch and short-circuit protection
2.3.Product oversize: 1530 mm×700 mm×1700mm.
3. Experiment content:
1.Cognition of training table;
2.Cognition of common used low-voltage instruments;
3.Usage of common electrical meters;
4.Inching and self-locking test of three-phase motor;
5.Postive and negative rotary test of three-phase motor, etc.
Total up 14 contents.
