XK-XNY-DDQC Electric Vehicle Power System Training Platform
Main functions:
Simulate full electric vehicle working principle.
Display main functions: Simulate full electric vehicle automobile power system working principle, set and debug faults.
Product overview:
1. Adopts with the original brand new Tianjing Qingyuan S605 electric vehicle system, drive motor, transducer, car charger, battery management system, transmission structure chart. Complete show each big system’s structure and working principle.
2. This training platform is inkjet with color circuit, which protected by organic glass, student could visual engine real object compare with circuit diagram, to know and analyze control system’s working principle.
3. Equipped with detection terminal, could direct test various sensor, actuator, battery management department, transducer, drive motor and other main device pin’s electrical signal, such as resistance, voltage, current, frequency, waveform signal, etc.
4. Training panel is installed with electrical motor meter, ampere meter, voltmeter, revolution meter, fully show electric car’s current, voltage changes during start, intermediate speed operate, high speed operate, stop, reverse and other working conditions. Panel distributes each system presentation device, and match with demonstrate actions; panel equipped with corresponding detection terminal and bug switch, convenient to process working principle’s explain and simulate bug exclusion. Setting detection terminal, real-time detect working condition.
Main parameters:
Size:1800*1000*1800MM
Net Weight:100Kg
