Automobile Engine training, XK-FDJ-2000AJR vehicle engine experiment device
A. Product Overview:
Engine assembly and control unit, the original vehicle wiring harness, combination instrument, sensor and actuator, fuel tank and the fuel pump assembly, battery, digital voltage meter, vacuum pressure gauge, fuel pressure gauge, ignition switch, cooling institutions, color circuit diagram panel, external detection terminal, intelligent fault setting system, safety protection device, movable bench, operation manual...
B. Main parameters:
Engine type: straight four stroke eight valve electronic controlled gasoline engine;
Displacement: 1.8L;
Working voltage: 12V DC;
Work environment: - 40°C-- 50 °C;
C. Main function:
1. The dynamic operation function: based on Santana 2000AJR engine assembly, equipped with the auxiliary control system, sensor and actuator, make sure the normal operation of an engine, dynamic demonstrate the working process.
2. The display function: through the original vehicle wiring harness connection combination instrument, vacuum pressure gauge, fuel pressure gauge and so on, can be real-time display the various state dynamic, static signal parameters during engine operation.
3. Detection functions: external detecting terminal are installed on the training platform panels, can be directly on the panel detection sensor, actuator, the engine control unit pin electrical signals, such as resistance, voltage, frequency, waveform signal.
4. Signal simulation function: can do signal simulation for each engine electronic control system sensor, and the real-time detect the change of running state of engine caused by the sensor input signal changes.
5. Self diagnostic function: equipped with computer data detection port, can be connected with special or general decoding apparatus, do ECU code query, read the fault code, clear fault code, read data stream, waveform analysis, actuator test self diagnosis function to the engine electronic control system...
6. Fault setting function: equipped with intelligent fault setting and assessment system, and with a device is adapted to the test questions library, examination questions library based on user demand for editing, can set a variety of common faults related to module pin . Installation of RJ45 network interface, equipment with serial RS-232, can use cable and other equipment fault setting device compose a network, by the main control computer controls each of the equipment fault settings, troubleshooting, parameter setting, remote start, information feedback, assessment score and other functions.
The advantage of our Product:
XINGKE Products Specifications:
The First-Class Vocational Teaching Equipment Supplier/Manufacturer in People’s Republic of China.
1.Good quality
2.Reasonable price
3.OEM Service
4.OHSMS 28001; ISO14001; ISO9001
XINGKE Mainly Products Range:
1. Electrical Automation Training Equipment
2. Electronic/Electrical Technology Training Device.
3. Air-Conditioning and Refrigeration Training Sets
4. Power-Electronics Teaching Appliance
5. Mechanical and Electrical Integration Educational Apparatus
6. Sensor and Robot etc. Training Model
7. Car Maintenance Training Equipment/ Auto Electrical/Teaching Demonstration Board
8. Iron-making/Steel Rolling/Nonferrous Metal Smeltery Virtual Production Line Simulation Training System and Construction Machinery Virtual Simulator.
9. Supply OEM Services.
