Weld Alternator
Negotiable
MOQ: 10 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
BOBIG
Model Number:
Gsa-180A
Payment & Shipping
Payment Methods:
Port of Shipment:
fuzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Fujian, China
Brand Name
BOBIG
Model Number
Gsa-180A
Specifications
Weld alternator1. Weld alternator 4.5kw
2. Weld alternator Brushless
3. Weld italy alternator 4mm
Weld alternator 4.5kw
- Welding&Generating Double-usd Machine.It has two type:Brush and brushless,
- It is adopted(AVR)Automatic Voltage Regulator maintenance to D.C welding steay.With 12V DC 8 A,The Voltage and frequency are available on request.It can provide lighting power supply when it is welding continuously.It is suited to work for the building site in the evening or the other lighting current.
Specification data:
| HD-W/GSa-W(welding&Generating Machine) | |||||
| Model Name | HD-W180A | Gsa-W190A | |||
| Frequency(HZ) | 50 | 60 | 50 | 60 | |
| Rated Power(KW)) | 4.5 | 5 | 4 | 4.5 | |
| RatedVoltage(AC)(V) | 110,220,230,240,110/220,120/240 | ||||
| Power Factor | 1 | ||||
| No-load welding voltage(DC)(V) | 50 | 85 | |||
| Rated Welding current(DC)(A) | 160 | 170 | |||
| Max Welding current(DC)(A) | 180 | 190 | |||
| Welding operating voltage(DC)(V) | 24-30 | 21-31 | |||
| Welding current adjustment(A) | 80-180 | 45-190 | |||
| Rated Speed(r/min) | 3000 | 3600 | 3000 | 3600 | |
| Duty cycle | 180A/20%,160A/50% | 190A/20%,170A%60% | |||
| Generator Voltage waveform distortion rate | 15% | 5% | |||
If you need any further information,pls kindly contact us.
