Copper-aluminium Radiators of PTL88/PTL89
Negotiable
/ Piece
3000 Pieces(Min. Order)
- xin gang
You May Like
Product Details
| Place of Origin | Beijing, China | Brand Name | pioneer | |
| Type | Other, copper-aluminium radiators |
Product Description
Specifications
1.Materail copper-aluminium adiators2.Code 1203
3.Height 360mm Width 80mm Length 80mm
4.center distance 300m
| Code | Model | Center distance(mm) | Length(mm) | Width(mm) | Height(mm) | Total Length (mm) | Water capacity (Litre) | Out put (w) | working pressure | nipple size |
| 1203 | PTL88-N/300-1.2 | 300 | 80 | 80 | 360 | 88N+12 | 0.196 | 98 | 1.2 | G3/4" |
| 1204 | PTL88-N/400-1.2 | 400 | 80 | 80 | 460 | 88N+12 | 0.222 | 123 | 1.2 | G3/4" |
| 1205 | PTL88-N/500-1.2 | 500 | 80 | 80 | 560 | 88N+12 | 0.247 | 147 | 1.2 | G3/4" |
| 1206 | PTL88-N/600-1.2 | 600 | 80 | 80 | 660 | 88N+12 | 0.273 | 174 | 1.2 | G3/4" |
| 1210 | PTL88-N/1500-1.2 | 1000 | 80 | 80 | 1060 | 88N+12 | 0.375 | 270 | 1.2 | G3/4" |
| 1212 | PTL88-N/1800-1.2 | 1200 | 80 | 80 | 1260 | 88N+12 | 0.425 | 321 | 1.2 | G3/4" |
| 1215 | PTL88-N/600-1.2 | 1500 | 80 | 80 | 1560 | 88N+12 | 0.502 | 379 | 1.2 | G3/4" |
| 1216 | PTL88-N/1500-1.2 | 1600 | 80 | 80 | 1660 | 88N+12 | 0.527 | 401 | 1.2 | G3/4" |
| 1218 | PTL88-N/1800-1.2 | 1800 | 80 | 80 | 1860 | 88N+12 | 0.578 | 438 | 1.2 | G3/4" |
| 1903 | PTL89-N/300-1.2 | 300 | 80 | 95 | 360 | 88N+12 | 0.181 | 110 | 1.2 | G3/4" |
| 1904 | PTL89-N/400-1.2 | 400 | 80 | 95 | 460 | 88N+12 | 0.213 | 132 | 1.2 | G3/4" |
| 1905 | PTL89-N/500-1.2 | 500 | 80 | 95 | 560 | 88N+12 | 0.244 | 154 | 1.2 | G3/4" |
| 1906 | PTL89-N/600-1.2 | 600 | 80 | 95 | 660 | 88N+12 | 0.276 | 185 | 1.2 | G3/4" |
| 1910 | PTL89-N/1500-1.2 | 1000 | 80 | 95 | 1060 | 88N+12 | 0.403 | 312 | 1.2 | G3/4" |
| 1912 | PTL89-N/1800-1.2 | 1200 | 80 | 95 | 1260 | 88N+12 | 0.466 | 342 | 1.2 | G3/4" |
| 1915 | PTL89-N/600-1.2 | 1500 | 80 | 95 | 1560 | 88N+12 | 0.561 | 409 | 1.2 | G3/4" |
| 1916 | PTL89-N/1500-1.2 | 1600 | 80 | 95 | 1660 | 88N+12 | 0.595 | 439 | 1.2 | G3/4" |
| 1918 | PTL89-N/1800-1.2 | 1800 | 80 | 95 | 1860 | 88N+12 | 0.656 | 472 | 1.2 | G3/4" |
