cast iron radiator for Algeria

Specifications

1.cast iron radiator
ing pressure up to 1.0Mpa
3.over 50 years using life
4.reasonable price
5.smooth surface

Specification and features of cast iron radiator

Code	Model	H(mm)	W(mm)	L(mm)	Center distance(mm)	Weight(kg)	Dissipation area(m2)	Heating Capacity(W)	Working pressure(≤Mpa)	Connection
2262	PTZY3-623-10	680	95	60	623	5.7	0.26	130	1.0	G1"
2362	PTZY4-623-10	680	130	60	623	7.2	0.34	162	1.0	G1"

1.Spray painting with epoxy resin, smooth and easy to clean.
2.Colourful and it can be made at customers' request.
3.Adapts to all kinds of water quality with the better properties than various steel and aluminium radiator.
4.Corrosion resistant with over 50 years of using life.
5.Changeable shapes, can be processed freely to fit for the structure of the room.
6.Bearing capacity up to 1.0Mpa , fit for the high-rises.
7.Reasonable price.
