Frp Grating Price,grate Plate,tree Grate Price

Frp Grating Price,grate Plate,tree Grate Price photo-1
Frp Grating Price,grate Plate,tree Grate Price photo-2
Frp Grating Price,grate Plate,tree Grate Price photo-3
Frp Grating Price,grate Plate,tree Grate Price photo-4
Frp Grating Price,grate Plate,tree Grate Price photo-5
Frp Grating Price,grate Plate,tree Grate Price photo-6
US$ 30 - 75 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
GRAD
Model Number:
1220*3660mm
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Tianjin/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Shandong, China
Brand Name GRAD
Model Number 1220*3660mm
Product Description

 Comparing with other floor materials, FRP moulded grating provides a series of benefits, unmatched impact resistance, while the strength-weight-ratio is only one-fourth of that of steel grating. It is easy to cut and install. FRP moulded grating is made of continuous fiberglass fully soaked in unsaturated polyester resin giving a uniform structure and perfect bi-directional mechanical properties.

Standard resins being used include Orthophthalic, Polyester resin, Isophthalic polyester, Vinyl ester resin. Vinyl ester grating provides extremely high corrosion resistance.
The surface of FRP moulded grating can be concave top, flat top, grit top,Decorative Pattern Cover,Grit Cover and Smooth Cover.



 FRP Moulded Grating Standard Panel

Thickness
(mm)
Panel size
(mm)
Mesh size
(mm)
Bar thick
(mm)
panel
Wt.per m2
Weight
(Kg)
25 1007x2007 40x40 6.5 12.8Kg 25.8
1220x3660 38x38 6.5 13.4Kg 60.0
1007x4007 40x40 6.5 12.8Kg 52.0
1220x3660 25x100 6.5 13.8Kg 62.0
1220x3660 38x38/19x19 6.5 16.8Kg 75.1

30 1007x4007 40x40 6.5 14.8Kg 60.0
1220x3660 38x38 6.5 14.7Kg 65.6
1220x3660 38x38/19x19 6.5 18.4Kg 82.2

38 1220x3660 38x38 6.9 18.7Kg 83.5
1007x4007 40x40 6.9 18.8Kg 76.0
1220x3660 38.1x152.4 6.9 16.0Kg 71.5
1220x3660 38x38/19x19 6.9 23.5Kg 105.0

40 1007x3007 40x40 7.0 19.8Kg 60.0
1007x4007 40x40 7.0 19.8Kg 79.9

50 1220x3660 50x50 8.0 21.3Kg 95.1



Application



frp grating price,grate plate,tree grate price

Packaging & Shipping

 Usually we use plywood package or naked package. Some of the products like fan coil unit or table tennis board have standard carton package. The shipping terms are LCL, 20’ container, 40’ container

 frp grating price,grate plate,tree grate price

Our Services

Before-sale services:

(1) Tell customers how to use our products and matters needing attention.

 (2) Guide customers to choose the best and economic product, recover the investment within short time.

 (3) Site inspection if you need.



In-Sale services:

(1)Quality control must be inspected strictly.

 (2)In accordance with the agreements stipulated in the contract.



After-sale services:

(1) If the project needs our installation guidance, we can send our engineer and translator. We can also send customers installation video to teach them how to fix and operate with

our product

(2) Usually, our product warranty is 18 months after leaving factory or 12 months after installation. within this months, all parts broken will be responsible for our factory.

(3) Regular contact with customer, consult with the customer feedback, come true with

the customer's two-way communication.
