6.5KW/KVA Kubota Diesel Generator With 1 Phase

Fujian Bobig Electric Machinery Co., Ltd.
6.5KW/KVA Kubota Diesel Generator With 1 Phase thumbnail-1
6.5KW/KVA Kubota Diesel Generator With 1 Phase photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
BOBIG or OEM
Model Number:
BK14S/BK14
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
FUZHOU
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name BOBIG or OEM
Model Number BK14S/BK14
Output Type AC Single Phase
Speed 1500rmp/1800rpm
Frequency 50HZ/60HZ
Rated Power 6.5KW/KVA
Rated Voltage 220,230,110/220 It up to your optional

Specifications

Kubota genset
Famous engine with stamford/Leroy somer alternator
Optional ATS or AMF
one year warranty
CE,ISO9001

6.5KW/KVA Kubota diesel generator (Optional for alternator)

KUBOTA series diesel generator
Specification data
Genset model BK11S-1
Prime Power of genset 6.5KW/KVA
Standby Power 7.2KW/KVA
KUBOTA ENGINEModelD1105-BG
TypeVertical 4 cycle liquid cooled Diesel
No.of Cylinders3
Bore*Stroke mm(in)78.0*78.4(3.07*3.09)
Combustion SystemE-TVCS
Displacement L(cu.in.)1.123(68.53)
Intake SystemNatural aspirated
Fuel Injection PumpBosch type PFR MD pump
Direction of RotationCounterclockwise(viewed from flywheel side)
Injection NozzleThrottle type
Compression Ratio22
Lubricating OilQuality better than CD class
Oil Pan Capacity L(gal)5.1(1.35)
Cooling SystemRadiator cooling
Starter Capacity V-A12-1.0
Alternator Capacity V-A12-30.0
Used FuelDiesel Fuel No.2-D(ASTM D975)
Fuel consumption 100% PRP2.2l/h(0.5Gal/h)
Fuel autonomy at 100% PRP11hours
Stand-by for 50HZ(1500rpm)kw,HP PS7.4(9.9)(10.0)
Leroy Somer AlternatorAlternator ModelLSA 40 VS1
Alternator manufacturerLeroy Somer
Exciter typeSingle bearing ,Brushless,Self-excited
Rated output continuous power6.5KW/kVA
Rated speed1500RPM
Rated frequency50Hz
Phase1
Rated Voltage220V(Available with customer requirements)
Power factor0.8
Voltage adjust range>5%
Voltage regulation NL-FL<+-1%
Insulation gradeH
Protection gradeIP23

Canopy size around 1790*970*1140mm



Warranty:Guarantee for one year or 1200hours from ex-factor date.During the repair time,BOBIG COMPANY will provide the free easy-damageable spare arts of diesel engine caused by our quality of production or raw material.After expiration,BOBIG COMPANY will supply cost spare part for you to repair it.



6.5KW/KVA kubota diesel generator with 1 phase6.5KW/KVA kubota diesel generator with 1 phase
