Pipe Welding Machine

Pipe Welding Machine photo-1
US$ 60 - 90 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Fujian, China
Model Number:
TIG200A
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen Port
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Fujian, China
Model Number TIG200A
Pulse Frequency 50/60Hz
Pilot Arc Current 10-200A
Rated Duty Cycle 60%
Dimensions 350*155*290mm
Usage Civilian welding
Voltage AC220V±15%
Power(W) 40W
Certification CE;CCC
Warranty 2 year
After-sales Service Provided Engineers available to service machinery overseas



Product Description
  • Specifications

  1. Has both TIG/MMA function
  2. High frequency ignition
  3. Compact size&lightweight
  4. Enery saving technology
  5. 2T/4T function available upon request
  6. Dual voltage availbale upon request

   Accessories
  • A, Earth Clamp 3m, 16mm ²,300A
  • B, Electrode holder 3m, 16mm²,200A
  • C, Torch wp-17
---------------------------------------------------------------------------------------------------




    Parameter/Model



                TIG200A        TIG-200

   Input Volatge (V)

 AC220V±15%   AC220V±15%
    Frequency     (Hz)                   50/60Hz           50/60Hz
    Rated Input Current (A)                   32.2/19.3           28
   No-load Voltage  (V)                   56          42
   Output Current Range (A)                   10-200           10-200
    Rated Output Voltage (V)                  28/18           18
    Duty Cycle (%)                   60            60
    No-load Loss (W)                  40           40
    Efficiency (%)                  85           85
    Power Factor                  0.93           0.93
    Insulation Grade                  F            F
    Housing Protection Grade                 IP21S            IP21S
    Net weight ( Kg)                 9           9

 Pipe Welding machine



 Pipe Welding machine









Packaging & Shipping



Packaging :   one pipe inverter welder  in one pc carton



Pipe Welding machine















Our Services

 2  year warrantly





Company Information

 Zhangzhou Honghui Electronic Equipment  Development co.,ltd Is a professional specializing in inverter dc welding and cutting equipment D&R, production, and sales of large welding equipment enterprises.  The company's core team has nearly 30 years of experience in welding, focusing on various metal welding machinery development, design, and the introduction of german's the most advanced welding technology and production processes, continuously introduce advanced technologym, high cost perfermance of welding equipment.



By gaining the certificate requirements of the ISO 9001:2000, the company has well developed a full range of products which have been certified with the CE,CCC certifcates by the authority organization.  The Products consist of ten series, which over 100 models in total:



Inverter MMA Welder Series



Inverter TIG DC Welder Series



Inverter MMA/TIG Welder Series



Inverter TIG AC/DC Welder Series



Inverter MIG Full Function Welder Series



Plasma Cutting Series



Inverter MIG/MAG Welder Series



Inverter IGBT TUBE MIG/MAG Welder Series





Pipe Welding machine
