Main Product: diesel engine, diesel generator, alternator and spare parts;
Diesel Engine Usage: Widely used for generator set, boat, wheel loader, truck, water pump, sand pump,
fire pump, construction machine, etc;
Diesel Engine Power Range: from 20kw up to 700kw;
Diesel Generator Power Range: from 30kw up to 700kw.
110kw 1500rpm Diesel Generator set 140kva Technical Parameters
| Genset Model (LD Brand) | LD112GF | |
| Rated Power/Speed (kw/r/min) | 112/1500 | |
| LD Diesel Engine | Engine Model | LD6BTAA5.9-G1 |
| Rated Power/Speed kw/r/min | 120/1500 | |
| Type | Vertical,inline,water-cooled,four stroke | |
| Intake Way | Turbocharged&intercooled | |
| Number of cylinders×bore×stroke(mm) | 6-102×120 | |
| Total dispalcement(L) | 5.9 | |
| Min fuel consumption (g/kw.h) | ≤195 | |
| Starting type | Electric | |
| Speed governor model | Mechanical | |
| Oil capacity(L) | 14~16 | |
| Low noise limit dB(A) | 98 | |
| Wattek Alternator (Stamford Technology) | Alternator nodel | 274E |
| Rated voltage(V) | 400/230 or 380/220 | |
| Current(A) | 202 | |
| Freq(Hz) | 50 or 60 | |
| Regulator approach | AVR | |
| Power factor(CosØ) | 0.8 Lagging | |
| Phase | 3Phase 4Wire | |
| Insulation Class | F/H | |
| Protection Class | IP22/IP23 | |
| Genset Packing | Net weight(kg) | 800 |
| Genset dimension L*W*H(mm) | 3000×1150×1450 | |
Our staff of sales and technical support is available to help you in selecting the right engine model for
your application as well as to provide you with catalog of our products for evaluation. At LD Power,
we are committed to providing the highest level of customer service, competitive pricing, speedy delivery
and a comprehensive, diesel engine product offering. Our ultimate goal is your satisfaction.

l Engines Applications Equipped our own LD6LA,6LM engines, lower fuel consumption, lower noise,
convenient maintanecne and share spare parts with Yuchai engines supply system;
l Alternator & Controller Wattek brand alternator 274, made by Stamford technoloty;
Smartgen controller 6120;
l Genset Characteristics 24V Electric start; radiator can meet environment temperature 50 degree.
110kw 1500rpm Diesel Generator set 140kva Maintenance Service
1.Warranty iterms will be issued by our own factory, which is simple and quick;
2.Warranty period will be 12 monthes or 1500 working hours from commissioning date;
3.Parts replacement under warranty will be sent (include sea freight and insurance) to buyers without charges;
4.Easy torn prts are excluded in the warranty, like plugs, condenser, fuse, battery, seal;
5.Problems caused by customer's incorrect man-made operation will be covered by the user;
6.Part use for overhual and ordinary maintanence will be offered by us in factory price;
7.Skillful engineers of us are available dispatched to customers place for training and service.
