Manufacturer Supply LD Brand 4D Series Diesel Engine Sand Pump

Manufacturer Supply LD Brand 4D Series Diesel Engine Sand Pump thumbnail-1
Manufacturer Supply LD Brand 4D Series Diesel Engine Sand Pump photo-1
US$ 2,800 - 3,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Usage:
Other, Sand Pump, Construction
Fuel:
Diesel
Contact Supplier Request Quote Chat Now
Liuzhou Long Dao Industrial And Trading Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Usage Other, Sand Pump, Construction
Fuel Diesel
Stroke 4 Stroke
Cylinder Other, 4 Cylinder
Cold Style Other, Water-cooled
Start Electric Start
Place of Origin Guangxi, China
Brand Name LD Brand
Model Number LD4D Series
Dimension(L*W*H) 1120x800x1000 mm
Weight 380 kg
Certification ISO9001:2008, CE
Warranty 12 Month
After-sales Service Provided Overseas third-party support available

Specifications

1. Germany, Yuchai Technology
2. Price less 30% than other brand
3. ISO9001, CE Approved Factory
4. Share Yuchai Parts

Manufacturer Supply LD Brand 4D Series Diesel Engine Sand Pump

       LD brand construction diesel engines 4D series is made & design by our own factory which technology

origin from Germany FEV, Yuchai companies and share parts with Yuchai supply system, it is said that

origine Yuchai parts are fully fit for LD engines maintanence.

       After 10 years experience manufacturer, LD engines have approved IO9001:2008, CE Certificates, and

owned a good quality.

Manufacturer Supply LD Brand 4D Series Diesel Engine Sand Pump



l   Advanced Technology & Design Origin from Germany FEV, Yuchai companies, with more compact structures, engine

      overhaul can met more than 12000 hours;

l   Common Parts Supply System Parts will share Yuchai engines parts supply system, easy to get in current market;

l   Environmentally Operation Fuel consumption will lower 205g/kw.h, with lesser vibration, noise;

l   Application Machines Small excavators, forklift, roller, water pump, sand pump, fire pump.

Engine

Model

LD4D

75G

LD4D

80G

LD4D

95ZG

LD4D

100ZG

LD4D

110ZLG

Rated Power/Speed kw/r/min

56/2200

60/2400

70/2200

75/2200

80/2200

Max Torque  (N.m/rpm)

265/1400~1600

340/1400~1600

430/1400-1600

Type

Vertical, In line, Water cooled, 4 Stroke

Intake Way

Natural

Turbocharged

Turbocharged & Inter-cooled

No-Cylinders×bore×stroke (mm)

4-108×115

Total displacement(L)

4.2

Min fuel consumption (g/kw.h)

≤205

Starting type

Electric

Oil capacity(L)

8-13

Low noise limit dB (A)

≤102

Flywheel Size

3#11.5’’

Net Weight (kg)

370-400

Dimension (mm)

1120x800x1000



Manufacturer Supply LD Brand 4D Series Diesel Engine Sand Pump Warranty

1.Warranty iterms will be issued by our own factory, which is simple and quick;

2.Warranty period will be 12 monthes or 1500 working hours from commissioning date;

3.Parts replacement under warranty will be sent (include sea freight) tobuyers without charges;

4.Easy torn prts are excluded in the warranty, like plugs, condenser, fuse, battery, seal;

5.Problems caused by customer's incorrect man-made operation will be covered by the user;

6.Part use for overhual and ordinary maintanence will be offered by us in factory price;

7.Skillful engineers of us are available dispatched to customers place for training and service;

Manufacturer Supply LD Brand 4D Series Diesel Engine Sand Pump





Mr.Guangbin Liang (Tony)

(Export/Sales Manager)

Tel: +86 18978043291       Fax: +86 (0)772 2875155

Email: guangbinliang(at)

Skype: guangbin.liang            QQ:491383357

Manufacturer Supply LD Brand 4D Series Diesel Engine Sand Pump
