SNB 0-8M Long Distance Safety Light Curtain Barrier, Safety Curtain Sensor, Light Barrier Sensor (IBEST)

Specifications

Long Working Distance Light Curtain
1.Dual relay / NPN / PNP output
2.Long Working distance 0-15M
3.Resolution : 40, 80mm

1. Features of STD series Long  Working  Distance Light Curtain :



*     Protection height: 0~15M, optional selection for users.
*     Light axis pitch: 40mm and 80mm.
*     Composed of separate emitter, receiver(reflector), controller, cable connector and installation bracket.

*     Fast response <20ms.
*     LED indicator for working status and malfunction.
*     Auto inspection function to avoid output wrong signals to control circuit.
*     Dual relay and to avoid output wrong signals for safety purpose.

*     Reset function: When light grating interdicted, equipment isn't able to work unless operator press Reset Button, for protecting safety of operator.

*     Output NPN or PNP.
*     Easy connection: With plug in connector and cable.

*     High anti-interference: Free from magnetic signals, stroboscopic light, welding arc other ambient light.

*     Common application, long endurance, easy to adjust light beam, high anti vibration.

*     When protection areas are not in a parallel (e. G: Vertical and horizontal), light curtain can be used in series.



     Application fields:  mainly used in the machine finishing processing to protect safety of operators, such as:
  - Presswork machinery
  - Shearing equipment
  - Metal cutting equipment
  - Automated assembly line
  - Automated solder line
  - Machinery transmission equipment
  - Three dimensional garage
  - Rubber, plastic processing machinery.
  - Other dangerous regions







2. Technical Specifications:

Property project Specific parameter Output NPN or PNP Controller Dual Relay Controller Intallation Inside Electrical Distribution Box Type Through Beam Response <20ms Cable 5M(with connector and cable) Power Supply DC 24V or AC 110/220V



Our company is a professiona manufacutures of:

1, Sensors: inductive proximity sensor, capacitive proximity sensor, photo sensor,  hall sensor, color mark sensor and analog sensor.



Welcome to contact us!
