M30 4M Long Distance Reflective Photo Sensor Switch, Reflector Photo Sensor Switch, AC Photoelectric Sensor Switch Photocell

Specifications

M30 PNP Type Photo Cell
1. DC 3 or 4 wire; with or without M12 connector
2. PNP/NPN Type ( NO /NC / NO+NC ), Ac 2 Wire
3. CE

1. Features of IBEST M30 PNP Type Photo Cell  :

--   Style: cylinder, diameter: 30mm.
--   Through-beam type, retro-reflective type and diffused-reflective type.

--   DC 3 wire or 4 wire; with or without M12 plug-in connector connection.
--   PNP or NPN; NO or NC or NO+NC
--   Light resource: Infrared LED
--   Strong anti-shock and anti-vibration.

--   Long detect distance: through-beam: 20m / retro-reflective type: 4M / diffused-reflective: 20~100cm

--   Fast response: through-beam: <5ms / diffusec-reflective: <3ms

--   Non-contact object detect: avoid the photoelectric sensor to contact the object directly, protect the inducing component from damage and extend the operation life of the sensor.

--   Detect any objects with different materials: detect objects by the light quantities reflected and received, detect objects such as glass, metal, plastic, wood, fluid...etc.

--   Identify object colors: according to the colors' reflectivity and absorptivity, the sensors detect the light that the object reflected and identify the colors.



--   High precision: precise electron circuit, can detect tiny objects with accurate position.

--   IP ratings: IP67
--   With Various other shapes: M12/M18 and square types.





2. Ordering Code

Model and Type Detecing type Out type Detecting distance range Current output Power supply Buy PES-T30NO20MD  Through-beam  NPN NO  20m  ≤200mA  DC 10-30V   PES-T30NC20MD  Through-beam  NPN NC  20m  ≤200mA  DC 10-30V   PES-T30PO20MD  Through-beam  PNP NO  20m  ≤200mA  DC 10-30V   PES-T30PC20MD  Through-beam  PNP NC  20m  ≤200mA  DC 10-30V   PES-T30NOC20MD  Through-beam  NPN NO+NC 4 Wrie  20m  ≤200mA  DC 10-30V   PES-T30POC20MD  Through-beam  PNP NO+NC 4 Wire  20m  ≤200mA  DC 10-30V   PES-T30DO20MD  Through-beam  DC NO 2 Wire  20m  ≤100mA  DC 10-30V   PES-T30DC20MD  Through-beam  DC NC 2 Wire  20m  ≤100mA  DC 10-30V   PES-T30AO20MA  Through-beam  AC NO 2 Wire  20m  ≤400mA  AC 90-250V   PES-T30AC20MA  Through-beam  AC NC 2 Wire  20m  ≤400mA  AC 90-250V   PES-R30NO4MD  Retro-reflective  NPN NO  4m  ≤200mA  DC 10-30V   PES-R30NC4MD  Retro-reflective  NPN NC  4m  ≤200mA  DC 10-30V   PES-R30PO4MD  Retro-reflective  PNP NO  4m  ≤200mA  DC 10-30V   PES-R30PC4MD  Retro-reflective  PNP NC  4m  ≤200mA  DC 10-30V   PES-R30NOC4MD  Retro-reflective  NPN NO+NC 4 Wrie  4m  ≤200mA  DC 10-30V   PES-R30POC4MD  Retro-reflective  PNP NO+NC 4 Wire  4m  ≤200mA  DC 10-30V   PES-R30DO4MD  Retro-reflective  DC NO 2 Wire  4m  ≤100mA  DC 10-30V   PES-R30DC4MD  Retro-reflective  DC NC 2 Wire  4m  ≤100mA  DC 10-30V   PES-R30AO4MD  Retro-reflective  AC NO 2 Wire  4m  ≤400mA  AC 90-250V   PES-R30AC4MD  Retro-reflective  AC NC 2 Wire  4m  ≤400mA  AC 90-250V   PES-D30NO1MD  Diffused-reflective  NPN NO  1m  ≤200mA  DC 10-30V   PES-D30NC1MD  Diffused-reflective  NPN NC  1m  ≤200mA  DC 10-30V   PES-D30PO1MD  Diffused-reflective  PNP NO  1m  ≤200mA  DC 10-30V   PES-D30PC1MD  Diffused-reflective  PNP NC  1m  ≤200mA  DC 10-30V   PES-D30NOC1MD  Diffused-reflective  NPN NO+NC 4 Wrie  1m  ≤200mA  DC 10-30V   PES-D30POC1MD  Diffused-reflective  PNP NO+NC 4 Wire  1m  ≤200mA  DC 10-30V

3. Technical Specifications:

Property project Specific parameter Detecting distance range Through-beam:20m / Retro-reflective: 4m/ Diffusec-reflective:1m Rated power supply DC:10-30V / AC:20-250V Current DC 3 Wrie: ≤200mA / DC 2 Wire:≤100mA / AC 2 Wire:≤400mA Resonse time Through-beam:<5ms / Retro-reflective & Diffused-reflective:<3ms Working angle Through-beam:3°-20°/Retro-reflective:1°-5° Voltage for transistor <1.5V Current consumption <20mA Different distance <15% Polarity reverse protection Yes Ambient light(LUX) Incandescent lamp:≤3000 / Sunlight:≤10000 IP ratings IP 67 Material Brass nickle plated or ABS
