Home > Electrical & Electronics > Sensor > Pressure Sensor > M12 Through Beam Laser Photo Sensor Switch, Photocell Sensor Switch NPN/PNP DC12-24V (IBEST)

M12 Through Beam Laser Photo Sensor Switch, Photocell Sensor Switch NPN/PNP DC12-24V (IBEST)

M12 Through Beam Laser Photo Sensor Switch, Photocell Sensor Switch NPN/PNP DC12-24V (IBEST) thumbnail-1
M12 Through Beam Laser Photo Sensor Switch, Photocell Sensor Switch NPN/PNP DC12-24V (IBEST) thumbnail-2
M12 Through Beam Laser Photo Sensor Switch, Photocell Sensor Switch NPN/PNP DC12-24V (IBEST) photo-1
M12 Through Beam Laser Photo Sensor Switch, Photocell Sensor Switch NPN/PNP DC12-24V (IBEST) photo-2
US$ 12 - 15 MOQ: 3 Sets
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
IBEST, SANLLEVI
Model Number:
LAS-T12PO8MD, LAS-T12NO8MD,
Contact Supplier Request Quote Chat Now
Zhongshan IBEST Electrical Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Zhongshan Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name IBEST, SANLLEVI
Model Number LAS-T12PO8MD, LAS-T12NO8MD,
Usage Other, laser spot
Theory Other, laser spot
Output Other, NPN or PNP, NO or NC or NO+NC

IBEST M12 Cylinder Laser Through Beam Sensor



1. Features:

*     M12 laser photo switch, power consumption ≤ 1mW.
*     Long detect distance: 0-8M.
*     Fast response <3ms.

*     DC 10~30V supply (or DC 5V special ordered) ; rated current ≤ 200mA.
*     NPN or PNP output; NO or NC.
*     Capability of working under sunlight without any influence.
*     Straight light: 2mm light spot, able to detect tinny objects: peanut, copper thread...etc.
*     Nickle plated brass, IP67 ratings, water resistant.

*     Advantage: laster switch emitter has small light sending angle, light is concentrated and strong, receiver is strong for receiving and feedback, capable of getting through rain, snow, frog, sand...etc, to avoid m malfunction.



2. Ordering Code
Model and Type Type Material Output Output Mode Detect Distance Buy
LAS-T12NO8MD  M12  Nickie Plated Brass  NPN  NO  SN=8M
LAS-T12NC8MD  M12  Nickie Plated Brass  NPN  NC  SN=8M
LAS-T12PO8MD  M12  Nickie Plated Brass  PNP  NO  SN=8M
LAS-T12PC8MD  M12  Nickie Plated Brass  PNP  NC  SN=8M

M12 Through Beam Laser Photo Sensor Switch, Photocell Sensor Switch NPN/PNP DC12-24V (IBEST)
Our company is a professiona manufacutures of:

1, Sensors: inductive proximity sensor, capacitive proximity sensor, photo sensor, hall sensor, color mark sensor and analog sensor.

2, Digital meter: temperature controller, digital counter, digital timer, digital frequency/tacho/linespeed meter, digital panel meter, analog panel meter ...etc.)
3, Solid state relay: single phase and 3 phase.
4, Rotary encoder and couplings.
5, Various type of cable and connectors..etc.
6, Pressure transmitters.
7, Safety light curtain.
M12 Through Beam Laser Photo Sensor Switch, Photocell Sensor Switch NPN/PNP DC12-24V (IBEST)



Welcome to contact us!

IBEST ELECTRICAL CO.LTD

wwwibestchinacom
