China pneumatic safety valves pressure reducing valveprofessional manufacturer
quick shipment
CEcertification
Pneumatic pressure reducing valve
Description
QFY-110 pneumatic valve pneumatic unit portfolio instruments auxiliary units, pneumatic pressure reducing valve can be compressed to 0.25 ~ 1MPa, air pressure reduced to a pneumatic instrumentation needed and have some stability pressure effect, pneumatic valve QFY-110 type output pressure range 0.002 ~ 0.2MPa, in addition to the supply of industrial pneumatic air source modular instrumentation and regulating device can also be used as needed for a given hand, the implementation of direct manipulation institutions, it is mainly for my plant supporting the use of pneumatic transmitters.
Technical parameters
Input pressure: 0.25 ~ 1MPa
Output pressure: 0.002 ~ 0.2MPa, setting valve is 0.14MPa
Output flow: When the output pressure of 0.14MPa, the flow of 3000l / h
Air consumption: less than 110L / h (pipeline pressure is 0.3MPa)
Weight: less than 0.9kg
Threaded joints are M10 × 1 pneumatic valve
About Us:
Xi'an Yunyi Instrument Co., Ltd. is a professional manufacturer that engaged in the fields of pressure measurement instrument, the chief engineer Mr Tian has more than 30 years on this area, he is one of the engineers who introduced the Rosemount technology. We specializing in developing high precision pressure transmitter and pressure gauges. And we also develop temperature transmitter, level transmitter, densitometer etc. They are widely used in chemical, petroleum, paper, electricity, city gas, environmental protection, water treatment and other fields.
If you need this Pneumatic pressure reducing valve , please visit the website
