Specifications
magnetostrictive level sensor1 Integrated isolation amplifier circuit
2 Imported chips
3 Strong lightning
4 Strong anti
Magnetostrictive level sensor
Parameters of magnetostrictive level sensor :
Measurement Type: linear displacement
Input voltage: 24Vdc (20.4 ~ 28.8Vdc)
Input protection: polarity protection: reverse voltage to 30Vdc, the maximum forward voltage up to 36Vdc
Current consumption: 50 ~ 140mA (depending on the working stroke varies)
Dielectric strength: 500Vdc (between power supply with equipment ground)
Output: 0 ~ 10Vdc and 10 ~ 0Vdc two kinds of output, the minimum load resistance 5KΩ
4 ~ 20mA and 20 ~ 4mA two output, maximum load resistance 700Ω
Resolution: infinite resolution (depending on the controller A / D and power supply ripple)
Repeatability: <± 0.005% FS
Linear Accuracy: <± 0.01% FS (minimum ± 90μm)
Refresh rate: 1200mm stroke of 0.5ms / 2400 mm stroke is 1.0ms
4800mm stroke 2.ms / 7600mm stroke of 5.0ms
Working temperature: -40 ~ + 85 ℃
Protection: IP67
Vibration test: 5g / 10 ~ 2000Hz comply with IEC standard 68-2-6
Impact Test: 50g single impact, in line with IEC standard 68-2-27
Pressure Rating: 350bar / 600bar peak
Mounting screws: M20 x 2
Body Material: Electronic warehouse anodized aluminum / measuring rod and mounting flanges 316 stainless steel
If you need this Magnetostrictive level sensor , please visit the website
