Help CenterCast Steel Rising Stem Gate Valve
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Taiwan, China
Model Number:
965-A
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
China Wholesale Brass Ball Valve PriceNegotiableMOQ: 1 Piece -
Stainless Steel Control ValveUS$ 5 - 15MOQ: 10 Units
-
Stainless Steel 3 Way Valve / Pressure ValveUS$ 5 - 15MOQ: 10 Units
-
Three Way Manifold Valve ManufacturerUS$ 1 - 20MOQ: 1 Piece
-
Specially Stainless Steel Valve Assembly Three Way ManifoldUS$ 1 - 20MOQ: 1 Piece
Place of Origin
Taiwan, China
Model Number
965-A
Specifications
Rising stem gate valveStem threads isolated from system fluid
Externally adjustable PTFE packing
Rising stem gate valve
Specification
PARTS NAME |
MATERIAL |
|
964 |
965 |
|
BODY |
A351-CF8 |
A351-CF8M |
BONNET |
A351-CF8 |
A351-CF8M |
STEM |
SUS304 |
SUS316 |
DISC |
A351-CF8 |
A351-CF8M |
GLAND |
A351-CF8 |
A351-CF8M |
GLAND PACKING |
PRFE(OPTION:GRAFOIL) |
|
HANDWHEEL |
DUCTILE IRON |
|
GASKET |
PRFE(OPTION:GRAFOIL) |
|
BONNET BOLT/NUT |
SUS304 |
|
GLAND BOLT/NUT |
SUS304 |
|
YOKE SLEEVE |
BRONZE |
|
| Maximum use pressure |
APPLICABLE CLASS 150 STANDAROS FACE TO-FACE:ANSI B 16.10
END FLANGES:ANSI B16.5
Pressure-Temperature Rating:ANSI B16.34
APPLICABLE JIS 10K STANDAROS: Face TO-Face:JIS B2002 END FLANGES:JIS B2238
Pressure-Temperature Rating: JIS B2238
unit:/mm
size |
1/2 |
3/4 |
1 |
11/4 |
11/2 |
2 |
21/2 |
3 |
4 |
5 |
6 |
8 |
10 |
12 |
L(Face To Face) |
108 |
117 |
127 |
140 |
165 |
178 |
190 |
203 |
229 |
254 |
267 |
292 |
330 |
356 |
H(Heught) |
185 |
210 |
220 |
270 |
270 |
320 |
380 |
445 |
523 |
606 |
710 |
920 |
1117 |
1324 |
D(Handwheel) |
90 |
90 |
100 |
100 |
140 |
160 |
180 |
200 |
225 |
250 |
250 |
300 |
350 |
400 |
About Us:
Xi'an Yunyi Instrument Co., Ltd. is a professional manufacturer that engaged in the fields of pressure measurement instrument, the chief engineer Mr Tian has more than 30 years on this area, he is one of the engineers who introduced the Rosemount technology. We specializing in developing high precision pressure transmitter and pressure gauges. And we also develop temperature transmitter, level transmitter, densitometer etc. They are widely used in chemical, petroleum, paper, electricity, city gas, environmental protection, water treatment and other fields.
If you need this Rising stem gate valve , please visit the website
