Help CenterThree-pieces PEEK High Pressure Ball Valve
Related Products
Three-pieces PTFE high pressure ball valve
Specification: T1-FM-QF3-002
Description: 316 material series ball valve 8mm tube fitting 4.8mm bore diameter .
Characteristic:
1.Max working pressure: 207 bar (3000 psig)
2.Working temperature range: -28°C to 232°C ( -20°F to 450°F)
3.Port:
1/8 to 2 tube thread
1/8’’ to 2’’ pipe butt welding or socket welding
1/2" to 2" and 12 mm to 50 mm Tube butt welding or socket welding
1/2" to 2" and 12 mm to 38 mm Tube two ferrule tube fitting
4.Three piece precision casting structure.
5. Valve body material:CF8M(316),CF3M(316L),CF8(304) and CF3(304L) are available for choose.
6. Valve seat material:PTFE,RPTFE,PEEK and alloy X-750(Alloy X-750) are available for choose.
7. Valve rod sealing material:PTFE,RPTFE,PEEK,Graphite are available for choose.
8. Inner size: 4.8 mm (0.19") to 38.1 mm (1.5").
9. Pneumatic or electric actuators are available.
10. Can make refractory design.
