Digital Vortex Flowmeter For Steam/Water/Compressed Air/Gases With CE Approved

vortex flowmeter Standard packing(or according to the customer request)

vortex flowmeter

Description of vortex flowmeter

vortex flowmeters, flow meters to measure the volume of gas, vapor or liquid volume flow, volumetric flow or standard conditions of mass flow rate based on Carmen (Karman) vortex principle. And as a flow transmitter used in automated control systems Vortex.

Parameters of vortex flowmeter :

Nominal by (mm): 15,20,25,40,50,65,80,100,125,150,200,250,300
Instrument Material: 1Cr18Ni9Ti
Nominal pressure (Mpa): PN1.6Mpa; PN2.5Mpa; PN4.0Mpa
Measured medium temperature (°C): -40 ~ +250 °C; -40 ~ +350 °C
Environmental Conditions
Temperature -10 ~ +55 °C, relative humidity 5% to 90%, atmospheric pressure 86 ~ 106Kpa
Accuracy class
± 0.5 Indication: the measurement of liquid
Measurement of gases or vapors:
Showing the value of ± 1.0, ± 1.5
Turndown ratio: 1:10; 1:15
Pressure loss coefficient: Cd <2.6
Output signal: optional 4-20mA or pulse
Power supply
Sensor: +12 VDC, +24 VDC (optional)
Transmitter: +24 VDC
Field display type: 3.2V lithium battery meter comes
Signal transmission lines: STVPV3 × 0.3 (three-wire), 2 × 0.3 (two-wire)
Mounting: flange clamping flange connection or integration
Transmission distance: ≤ 500m
Signal line interface: internal thread M20 × 1.5
Explosion levels: ExdIIBT6
Protection: IP65
Allow vibration acceleration: 1.0g

Features of vortex flowmeter :

No moving parts, long-term stability, simple structure for easy installation and maintenance
Using interference cancellation circuit and anti-vibration sensor head, has certain anti-vibration performance environment
Ultra-low-power single-chip microcomputer technology, Section 1 3.2V10AH lithium batteries can be used for more than 5 years
Software for instrument coefficient nonlinear correction to improve measurement accuracy
Pressure loss, wide range
Cumulative traffic using EEPROM brownout protection, the protection of longer than 10 years
