portable hardness tester for all metallic materials

portable hardness tester Standard packing(or according to the customer request)

Specifications

 high accuracy portable hardness tester

Description

MH210 Portable Hardness Tester whole Chinese self-powered high-speed thermal printer connected to the PC with the humane processing software combines two data processing scheme is MH210 unique advantage. Site printing convenient and quiet operation, flexible operation, to meet the different needs of users of the site personalization. Low-power design, connected to the computer for data exchange, mass storage. Low-power design, no less than 100 hours of standby time, AA fifth ordinary battery, portable, replaced by more flexible. Particularly suitable for field work and field operations.

Technical parameters:
Measurement Range: (170-960) HLD, (17-68.5) HRC, (19-651) HB, (80-976) HV, (30-100) HS, (59-85) HRA (13 -100) HRB
Measuring direction: support 360 º (vertically downward, oblique, horizontal, oblique, straight up)
Hardness standard: Leeb (HL), Brinell (HB), Rockwell B (HRB), Rockwell C (HRC), Rockwell A (HRA), Vickers (HV), Shaw (HS)
Display: Dot Matrix LCD, 128 × 64 dot matrix LCD
Data storage: Up to 500 groups (impact times 32 ~ 1)
Operating voltage: 3V (2 AA-size alkaline batteries in series)
Continuous working time: about 50 hours (without backlight)
Communication interface: RS232

Applicable materials:
Steel and cast steel, alloy tool steel, stainless steel, gray iron, ductile iron, cast aluminum, zinc alloys (brass), copper-tin alloy (bronze), copper, forged steel

Working conditions:
Ambient temperature: Operating temperature -20 ~ +60 °C; Storage temperature: -30 °C ~ +60 °C
Relative humidity ≤ 90%;
Surroundings without a strong vibration, strong magnetic fields, non-corrosive medium and severe dust.

Features:

1 completely sealed metal enclosure, compact, high portability, reliability, suitable for harsh operating environments, strong resistance to vibration, shock and electromagnetic interference, durable;
2 based Leeb hardness measuring principle, can detect a variety of metal materials. Measuring a wide range, there is no limit on the measurement of the workpiece shape and support 360 º measuring direction, and has shown the value of the boot software calibration feature to better ensure accurate data applicable in any industry with different norms and standards.
3 system supports a variety of hardness's Richter (HL), Brinell (HB), Rockwell B (HRB), Rockwell C (HRC), Rockwell A (HRA), Vickers (HV), Shore (HS). Measurements were measured before and after the conversion can be performed in parallel between the hardness of the system's.
4 excellent compatibility, seven kinds of impact device without the need for calibration of automatic identification. Shaped impact device and a series of ring-shaped support a reasonable price to meet the greatest needs of different customers in different areas.
5 full Chinese big screen 128 * 84 dot matrix LCD display with EL backlight support for easy use in dimly lit environments.
6 Host panel full Chinese menu operation, circuit design embodies the concept of humanity, one-button switch material and hardness arbitrary system's simple and convenient.
7 232 Plug and Play with common interfaces, standard configuration with a PC connected to the computer data processing software and micro-site high-speed thermal printing devices. Convenient and flexible real-time processing of field data.
8 large-capacity storage up to 500 groups (impact times 32 ~ 1) hardness measurements, each single measurement data including value, average, measurement date, impact direction, frequency, materials, hardness, and other information. Connected to a computer using the software also enables mass storage.
9 on the hardness value can be pre-set lower limits, out of range alarm, facilitate the needs of the user batch testing.
10 Support "Forged (Steel)" material, when using the D / DC type impact test "forged" sample, HB values can be read directly, without manual look-up table.
11. With automatic sleep, energy-saving features such as automatic shutdown, low-power design, Section 2 AA AA batteries for easy replacement, battery reliability stronger.
12. Two-year full warranty, consumable consumable parts prices qualified.
13. Dimensions: 132 X 76.2
14. Total Weight: 345g
