High quality bottle series flat/convexity screen printer for LC-PA-400E
Our cylinder screen printer is multifunctional screen printing machine. it suitable to print on flat, round, oval shaped products.such as metal, plastic, ceramic, glass, wood etc...Printing objects such as lipstick, cosmetic bottles, scour bottles, drink bottles, oil-filter shell etc...
Cylinder screen printers can print one color at one time. Once replacing frame and ink, they can print 2, 3^colors.
Parameter:
1. Model number: LC-PA-400E
2. Product appearance: Round /oblate /flat
3. (Round)Max. Printing diameter: Φ120mm
4. (Round)Max printing arc length: L: 370mm
5: (oblate)Max printing diameter: 500mm
6...(flat) Max printing area: 320*; 220mm
7. Printing Speed: 1200 PC/H
8. Machine/ Weight: 145kg
6. Air pressure: 0.5Mpa
7. Voltage power: 220V/ 60HZ or 110V/50HZ
Model number |
LC-PA-300E |
LC-PA-400E |
LC-600E |
LC-700E |
LC-1200E |
(Round)Max Printing diameter |
82 mm |
120mm |
180mm |
220mm |
375mm |
(Round)Max printing area |
300×260mm |
300×360 mm |
300×570mm |
350×670mm |
420×1170mm |
(oblate)Max printing diameter: |
420mm |
500mm |
/ |
/ |
/ |
(flat) Max printing area |
260*220mm |
320*; 220mm |
/ |
/ |
/ |
Max Workpiece rake |
<14° |
<14° |
<14° |
<14° |
<14° |
Air pressure |
6bar |
6bar |
6bar |
6bar |
6bar |
power |
50W |
50W |
50W |
50W |
50W |
Voltage |
AC110V/220V |
AC110V/220V |
AC110V/220V |
AC110V/220V |
AC110V/220V |
Printing speed |
1300P/H |
1200P/H |
1100P/H |
900P/H |
800PH |
Machine appearance(mm) |
850×850×1280 |
1080×850×1280 |
1200×1100×1450 |
1200×1180×1450 |
1720×1600×1650 |
Machine weight |
120kg |
145kg |
200kg |
210kg |
230kg |
Advantages
1. Fully automatic control by microcomputer & easy handling
2. Four figures automatic counter
3. Round printing function (taper section)
4. Automaticoil scrabbing, oil return and lifting table
5. Adujustability of routs and speeds
6. Self-poise scraper to balance printing pressure
7. Adjustable table (fluctuation & round) and netting easel (fluctuation & both sides)
8. High precision and easy & quick adjustability
Main Parts FESTO cylinde made by Geramny
Application area detergent bottles, Pens, beverage bottles, cups, cans, , Cosmetics package box, lipstick tube
Shipping way |
By sea, by air, by express |
Delivery time |
Within 7 days from the receipt of payment |
Loading seaport |
Shenzhen or Hong Kong, China |
Should any more informations be required,please feel free to contact with us.
1 .The guarantee time is 1 years, and maintain is lifelong.
2. We will make sure the machine all work well before package.
3.Your inquiry related to our prduct &price will be replied within 12 hours .
4.Our company have 25 years experience in the printing file.
Luen Cheong Printing Equipment Limited is specializing in manufacturing LC brands including luding :various pad printer, silk screen printer, hot foil stamping machine, UV Curing machines & cliche making machine for 25 years.
2. Q:Can you send me the video to show how the machine works?
A:certainly,we have made video of every machine and uploaded them to Youtube.
3. Q:How can I know your machine works well?
A:Before delivery,we shall test the machine working condition for you.
4. Q:How can I know your machine is designed for my product?
A:You can send us samples of your product and we test it on machine.
