2016 new Chinese manufacturer DJ-6A Holiday Detector Oil And Gas Pipeline
DJ-6A Holiday Detector
The product application scope
The instrument can use different thicknesses of glass-lined, glass, steel, coal tar epoxy coatings and rubber linings, the instrument lightweight, simple operation, stable and reliable, battery-powered, it is particularly suitable for field operations, widely used in chemical , petroleum, rubber, ceramic industry, is used to detect metal corrosion coating quality tool.
Holiday detector is a dedicated instrument for the detection of metal corrosion coating quality ,through a variety of coating the surface of a conductive substrate plus a certain amount of pulse voltage, such as the coating is too thin, metal or a leak pinhole leak, when the pulse voltage throught the coating surface produce a spark discharge gap formation breakdown, while a pulse is sent to the alarm circuit signal to the alarm sound the alarm, and thus achieve the purpose of detection of coating.
DJ-6 (A)-type spark leak detection Thickness: 30um ~ 1.5mm , the output high voltage: 600V ~ 8000V
can be customized according to your specific inspection requirements.
Technical parameters
Type |
DJ-6A
|
measurement range |
30μm~1.5mm
|
output voltage |
600v~8000v
|
battery |
12V / 2800mA
|
power consumption approximately |
6W
|
backlight |
Automatic backlight |
|
|
operation panel |
3 liquid crystal display output voltage, touch panel
|
Alarm |
function Earphone alarm and buzzer alarm |
The main parts
DJ-6
1. host ×1
2. high voltage probe ×1
3. brush(brush / straight brush)×2
4.connecting rod ×1
5. headphones ×1
6.strap ×1
7. fuse ×2
8.manual ×1
9.warranty card ×1
10. charger ×1
11.grounding wire ×1
12.grounding rod ×1
13. packing box ×1
Q1: I want to buy your products, how can I pay?
A :You can pay via T/T , T/C, Western Union,MoneyGram or other payment terms we reach agreement.
Q2: How can you guarantee the quality?
A: One year's warranty against B/L date.
If You meet with quality problem, we promise to responsible for it.
Q3: If we don’t find what we want on your website, what should we do?
A: You can email us the descriptions and pictures of the products you need, We will check whether we can make it.
Q4: Can we buy 1 pc of each item for quality testing?
A: Yes, we understand quality test is important and we are glad to send 1pc for quality testing.
