HCH-2000D Ultrasonic Thickness Gauge

HCH-2000D Ultrasonic Thickness Gauge thumbnail-1
HCH-2000D Ultrasonic Thickness Gauge photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
BANNERGLOBAL
Model Number:
HCH-2000D
Contact Supplier Request Quote Chat Now
Shandong Banner International Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name BANNERGLOBAL
Model Number HCH-2000D

HCH-2000D ultrasonic thickness(economy type)





1.2000C-type gage small size, low power consumption,

      touch buttons, simple operation.

2. automatic proofreading zero,

      the system can correct its own errors.

3.large-screen LCD backlit display.

4.data transmission, RS232 interface,

     can be connected to a small printer or PC.

5.five kinds of probes can be arbitrarily chosen match



Technical parameters:

Type HCH-2000C

Measuring range 0.7~199.9mm(45# steel)

Accuracy 0.1mm

Error value 1% thickness values±0.1mm

Tempreture of the material -20℃~550℃(depending on the probe)

Velocity range 1000~9990 m/s

Probe Standard equipped with 5MH probe, the probe can also choose the others

Data processing Can store 600 measurement data, can be connected to a printer and pc

Power Two 1.5V AAA batteries

Auto power off Automatic power standby after five minutes

Display Screen Black and white display Liquid crystal(LCD), 100* 100, automatic backlight

Show information Coupled instructions, measurement rate

Operating environment Temperature -10 ℃ ~ 60 ℃, relative humidity <90





Random accessories                      Options:

1,HCH-2000C host        1                Full series of probe selection



2,the probe (φ8 probe)    1               ( high temperature,cast iron,smalldiameter probe)



3,couplant              1                      Toolbox



4,Manual          1                          Printer



5,warranty card, certificate   1          Computer connect cable



6,two AAA batteries      1



7,suitcase          2



8,step test block (optional)     1







 Material



Steel

Velocity(M/S)

Material

Velocity(M/S)

Steel

 5900

Chrome

6200

Cast iron

4600

Copper

 4700

Brass

4640

Gold

3240

Aluminum

6400

Plexiglass

2730

Stainless steel

5790

Lead

2400

Tin

3230

 Zinc

4170











After-sale service



Each of our products the factory have to undergo a rigorous inspection.



Ke Dian instrument provides reliable quality and responsible service for ranging series instrument.



To provide one year warranty.



The warranty is a random warranty card shall prevail.





Company Information

Shandong Banner International Trade Co., LTD.,  is your most reliable test helper in material testing industry. Bannerglobal is our brand. The founder and main leaders of our company worked in MTS Systems Corporation more than ten years and provided solutions for various demanding and extremely complex material testing in many fields of China. Our goal is to create the best test experience for customers by providing the best quality products, professional technical support and world-class service to ensure accuracy, repeatability and reliability of test data.

Our product catalog:

 Electronic universal testing machine

 Hydraulic universal testing machine

 Electronic torsion test machine

 Tensile testing machine

 Pressure testing machine

 Pendulum impact testing machine



HCH-2000D ultrasonic thickness gauge

Packaging & Shipping

Packed by standard export fumigated wooden cases.

Ship from Qingdao port, is expected to arrive about 30days

HCH-2000D ultrasonic thickness gauge
