Large format buckets heat transfer machine 20L bucket roller heat transfer machine
This machine is used to plane and round objects heat transfer and hot stamping.
Large format buckets heat transfer machine 20L bucket roller heat transfer machine
Item |
Specification |
Qty |
Unit Price |
Large size Heat transfer machineLC-TC-350R |
1.Max stamping diameter: L 280* φ300mm 2.Heating power(can be customize): 2000W 3.hot head outer diameter 100mm /inner diameter of 30mm 4.Stamping temperature range of options: room temperature reach 280 degrees Celsius 5.Stamping time :0-99 seconds 6.Stamping pressure range of options: ≤250kgf -100kgf (7bar) 7.Stamping speed: 120pcs / hr 8.Power: 220 V/ 50Hz 9.Machine weight:500KG 10.Dimensions: 1400 × 1000 × 1900mm |
1set |
$6000- 7000 |
|
Remark: 1. Price Term: FOB Shenzhen, China. 2. Payment Term: 100% T/T in advance. 3. Loading time: 7days after receipt of payment. 4. Package: machine wrapped with PVC film, package in wooden case.
| |||
Here is the video show the machine working:
Features:
1 .An electronic controller IC integrated multifunction procedures to ensure that the machine to flat stamping , roll stamping , flat stamping and round surface, such as a multi-purpose pressure round running.
2 .Gilding press elbow mechanism design, strong steady pressure of 250kgf, under hydraulic pressure, up to 1 ton.
3 .Stamping pressure, temperature, hot pressing time is adjustable.
4 .operating panel with emergency stop device, easy to operate ,safe and fast.
5 .the fixtures rotation speed pressure is adjustable,the time is adjustable .
6 .automatic collection feeding is adjustable. Taiwan motor, can be customized for the two-speed winders cover a bit more precise, go within membrane accuracy 0.5mm.
7 .installation photocell (Taiwan's Yangming electric eye, 250 times per second high-precision motion) to locate the point of thermal transfer paper with precise tracking control.
8 .lifting stamping head height adjustable, stamping 300MM larger workpieces. Taiwan gold solenoid valve precise control, the German NASS coil stable and durable. All screws are made of 12.9, more stable and more durable.
9 .with emergency stop safety devices to protect the safety of the operator.
Large format buckets heat transfer machine 20L bucket roller heat transfer machine
Large format buckets heat transfer machine 20L bucket roller heat transfer machine
Shipping way |
By sea, by air, by express |
Delivery time |
Within 7 days from the receipt of payment |
Loading seaport |
Shenzhen or Hong Kong, China |
Luen Cheong Printing Equipment Limited is specializing in manufacturing LC brands including luding :various pad printer, silk screen printer, hot foil stamping machine, UV Curing machines & cliche making machine for 25 years.
The other hot sale items:
Top 1:LC-6090P precision advertisement screen printing machine
top 2: desktop UV curing machine
A:we are factory manufacture of printing machine and we provide perfect OEM and after- sale service.
2. Q:Can you send me the video to show how the machine works?
A:certainly,we have made video of every machine and uploaded them to Youtube.
3. Q:How can I know your machine works well?
A:Before delivery,we shall test the machine working condition for you.
4. Q:How can I know your machine is designed for my product?
A:You can send us samples of your product and we test it on machine.
