Shandong Banner International Trade Co., Ltd.: Jining, Shandong, China; Main products: Universal testing machine, Pressure testing machine, Impact testing machine, Bending testing machine, Testing machine accessories

Home > Products > MTS Testing Systems > Most popular reasonable concrete compression testing machine price

Most popular reasonable concrete compression testing machine price

FOB Price

US$ 10,000 - 30,000 / Set

1 Set(Min. Order)

Port QINGDAO
Payment TermsT/T Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shanghai, China	Brand Name	MTS
Model Number	CBT1000	Power	Electronic
Usage	Compression Testing Machine

Product Description

Most popular reasonable concrete compression testing machine price

Product Description

This product is suitable for compressive strength test of bricks, stones, cements and concretes, which can also be used for compressive properties test of other materials. The machine adopts micro flow valve, high-precision pressure sensor, and computer automatic constant loading control, which ensures high control precision and good reliability, it also uses electric screw lift to adjust the test space; the operation is easy and convenient.

CBT1000 Hydraulic Compression testing machine/ Concrete compression test machine Main function:

It is specially used to test the flexural strength of concrete, and it can meet the requirements of the concrete flexural test in the test method of mechanical properties of ordinary concrete, and also meet the requirements of ISO, ASTM and other standards for cement mortar materials testing.

CBT1000 Hydraulic Compression testing machine/ Concrete compression test machine Technical parameters:

Model		CBT1504,CBT1105,CBT1205,CBT1305
Measurement parameters	Maximum test force	50kN,100kN,200kN,300kN
	Accuracy class	1
	Test force measurement range	Full range 0.2%~100%
	Column number	2
	Two column net distance	300mm
	Test force resolution	Maximum test force 1/300000
	Test force measurement accuracy	Value ±1%
Control parameter	Force control range	0.02-5% FS/s
	Relative error of force control	±1.0%
	Upper and lower pressure head	180mm
	On the span	150mm/100mm
	Under the span	450mm/300mm
	Branch roll length	160mm
	Branch roll diameter	Φ30mm
	Maximum stroke	100mm
	Maximum speed	50mm/min
Other	Motor power	1.5kW
	Host size	12307001650
	Power Supply	380V/50HZ
	Weight	1100kg

Meet standards:

GB/T10128-1998 "metal room temperature torsion test method"

Meet standards:

Test method of mechanical properties of ordinary concrete GB/T50081-2002

Application industry:

Measurement and quality control; high school; Research Institute; commodity inspection and arbitration, technical supervision departments; building materials ceramics; other industries.

Original configuration:

1 sets of concrete anti bending device

Scalable configuration:

Protective cover

Packaging & Shipping

Packaging& Shipping:

Fumigation and by standard export wooden case.

Ship from Qingdao port, is expected to arrive about 30days

Mobile: +8615866073062

Skype: betty_3541

Tel: +86 537 3167400 Fax: +86 537 3165401

Shandong banner international trade Co.,Ltd

Web:

www.bannerglobal.en.china.cn

Our service

1. Pre-service

24 Hours online service for your consult.

Help choose right model,and a series of service,person,advise.

2. Middle service

--Give you best offer

--Provide discount for many sets order

--Do customer's request:

--Choose payment term you convienent.

--Promptly production and delivery,inform you in time.

--Can provide invoice value as you like to decrease your tax.

3. After sale service

--1 year warranty service and all life maintenance.

--Technical Egineer are avalible for oversea trainning.

--Free change for some parts

--Remote control technical consult

--Free installation DVD

--Maintenance plan

4,Commitment:

We will sign a letter of commitment while we sign the contract, which will improve your confidence to us.

5,Good Packaging:

Good Packaging: Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
