Fiber Optic Converter 16 Channel Digital Video Optic Converter / Transceiver

     Fiber Optic Converter 16 Channel Digital Video Optic Converter / Transceiver

16 Channel Fiber Optic Converter Digital Video Optic Converter / Transceiver

• Excellent performance with good price
• High-quality metal case
• Good quality of power supply ( working more than 3-4 years)
• Professional package & fast delivery
• 2 years warranty
• CE, FCC & RoHS Certificate

16 Channel Vide fiber optical video transmitter and receive can simultaneously transmit 16 channel of 8 bit digitally encoded broadcast quality video / reverse or bidirectional data / unidirectional or bidirectional audio / Ethernet / Telephone / Dry contact over one single mode or multimode optical fiber. These multiplexers are typically used in applications where the cameras have PTZ capabilities. Plug and Play design ensures the ease of installation and operation. Electronic and optical adjustments are never required. LED indicators are provided for instantly monitoring system status. Devices are available for either standalone or rack-mount installation ,which is suitable for different working environment.

Features:

• 8-bit digitally encoded and non-compression broadcast quality video transmission
• Directly compatible with NTSC, PAL, and SECAM CCTV camera systems and support RS-232, RS-422, and RS-485 data protocols;* Support any high-resolution video signal
• Automatic compatible PAL, NTSC and SECAM video system
• Power supply and other parameter state indication, which can monitor the operation condition of system
• Support no-damage regenerative trunk of video
• Constant input optical power, and large dynamic range ,no Electrical or Optical Adjustments Required
• Special ASIC design
• Hot-swap function
• Stand-alone type or card-type installed in 19’’ 2U or 4U rack-mount chassis

Application:

• Intelligent Transportation System
• Connection of Sub-network for Surveillance Center
• Public Security Surveillance
• High Way & Toll Station Surveillance
• Industrial Closed Circuit Television Surveillance

 EPE protective box & Carton

We aim to provide professional services to meet consistently customer's requirements keeping quality & cost on priority. OEM is highly Welcome.
